Chapter 8: Port Trunking
Section I: Basic Operations 142
The Create LACP (IEEE 8023ad) Aggregator menu is shown in Figure
39 on page 140.
Figure 40 Create LACP (IEEE 8023ad) Aggregator Menu
5. Configure the parameters as necessary. The parameters are defined
here:
1 - Aggregator
Specifies a name for the aggregator. The name can be up to twenty
alphanumeric characters. Spaces are allowed, but special characters,
such as asterisks and exclamation points, are not. Each aggregator
must have a unique name.
2 - Adminkey
Specifies a unique adminkey value for the aggregator. The value is
entered in hexadecimal. The range is 1 to FFFF. For background
information, refer to Adminkey Parameter on page 127.
3 - Distribution Mode
Sets the load distribution method. Possible settings are:
❑ SRC MAC - Source MAC address
❑ DST MAC - Destination MAC address
❑ SRC/DST MAC - Source address /destination MAC address
❑ SRC IP - Source IP address trunking
❑ DST IP - Destination IP address trunking
❑ SRC/DST IP - Source address /destination IP address
The default is SRC/DST MAC. For background information, refer to
Load Distribution Methods on page 130.
Allied Telesyn Ethernet Switch AT-8524M - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Create LACP (IEEE 802.3ad) Aggregator
1 - Aggregator ..................
2 - Adminkey .................... 0x0000
3 - Distribution Mode ........... SRC/DST MAC
4 - Port Range ..................
C - Create Aggregator
R - Return to Previous Menu
Enter your selection?
