AT-S62 Menus Interface User’s Guide
Section II: Advanced Operations 339
Displaying the Routing Table
The routing table is used by the switch when the IP address of a remote
node specified in a management command is not on the same physical
network as the switch. The table contains the IP address of the next hop
to reaching the remote network or device. For example, the switch
might refer to the table if you instructed it to download a new AT-S62
image file from a network server that was on a different physical
network.
To view the route table, perform the following procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 7 on page 55.
2. From the System Administration menu, type 9 to select System
Utilities.
The System Utilities menu is shown in Figure 9 on page 61.
3. From the System Utilities menu, type 6 to select Networking Stack.
The Networking Stack menu is shown in Figure 118 on page 335.
4. From the Networking Stack menu, type 4 to select Display Route
Table.
The Display Route Table is shown in Figure 120.
Figure 120 Display Route Table
The information in this table is for viewing purposes only. The
columns are defined here:
Allied Telesyn Ethernet Switch AT-8524POE - AT-S62
Production Switch
User: Manager 11:20:02 02-Jan-2004
Display Route Table
Destination Mask Next Hop Interface
---------------------------------------------------------------
127.0.0.0
255.0.0.0 127.0.0.1 loopback
169.254.0.0 255.255.0.0 169.254.37.1 eth0
169.254.37.1 255.255.255.255 127.0.0.1 loopback
U - Update Display
R - Return to Previous Menu
Enter your selection?
