542
Network AUX Remote
Panel
A network AUX remote panel is a function that provides a
simple connection of an MKS-R3210/R1620 Remote
Control Panel with a switcher, and uses the MKS-R3210/
R1620 Remote Control Panel as a switcher remote panel.
You can control the switching of cross-points on a
switcher from a remote panel on the network.
In a simple connection, the MKS-R3210/R1620 Remote
Control Panel and switcher are connected via the switcher
control station, without using LSM (Live System
Manager).
Network AUX remote panel restrictions
• Up to 16 remote panels can be configured for a single
control panel.
• Simultaneous use with an MKS-8080/8082 AUX Bus
Remote Panel is not supported.
• The network AUX remote panel function is not available
if the MKS-R3210/R1620 Remote Control Panel is
connected to an LSM.
• The network AUX remote panel function is not available
if NS-Bus protocol control is enabled on the switcher
control station.
• The following function and settings restrictions apply to
a remote panel.
Network AUX remote panel settings
The following settings are required in order to use the
network AUX remote panel function.
MKS-R3210/R1620 Remote Control Panel
settings
On the Network Settings page of the web menu, configure
the network (LAN1).
For details about setup, refer to the ICP-X7000 Installation
Manual and the MKS-R3210/R1620 Operating
Instructions.
Switcher control station settings
Configure the following in Maintenance Menu.
• AUX Remote Panel Config screen
Set the remote panel connection to use with the target
control panel.
• Network Setting screen
Allow access if the switcher control station functions as
an NTP server.
For details about setup, refer to the ICP-X7000 Installation
Manual.
Switcher settings
To use the same cross-point settings as the switcher on a
remote panel, copy the cross-point assign table in the
Engineering Setup >Panel >Xpt Assign menu (7322).
For details, see “Copying Cross-Point Settings”
(page 417).
Remote panel connection status
You can check the remote panel status in the Diag >System
Info >Network Aux Remote Status menu (7422).
For details, see “Remote Panel Connection Status”
(page 496).
Item Restrictions
Functions The following functions are not
available.
• Global salvo
• Protect
• Monitor
• Retrace
• Linkage
Levels Only 1 to 8 are available.
Operation
button colors Set to “Local”
(Color Settings on the Display Settings
page)
Source/
destination
names Select from the following two types of
alias names.
(Alias Name Lists page)
• Source name set on the switcher,
and fixed bus name
• Type+Num name
