473
4
Select the M/E or PGM/PST link source, then press
[M/E Set].
5
In the
destination).
6
Select the M/E or PGM/PST link destination, then
press [M/E Set].
To also link operations other than transition
execution
Press [Transition Only], turning it off.
To release the link
Select the link number and press [Clear].
Setting Key Transition Links
The operations which can be linked are as follows.
• Auto transition
• Key on/off
1
In the Engineering Setup >Switcher >Link menu
(7336), press [Key Trans Link].
The Key Transition Link menu (7336.7) appears.
The status area shows the link number list on the left
and a list of the keys that can be selected on the right.
2
Select the target link number to set.
3
In the
source).
4
Select the key for the link source, and press [Key Set].
5
In the
destination).
6
Select the key for the link destination, and press [Key
Set].
To release the link
Select the link number and press [Clear].
Setting a Color Corrector Link Group
You can configure an AUX bus color corrector link group.
1
In the Engineering Setup >Switcher >Link menu
(7336), press [Aux Bus CCR Link].
The Aux Bus CCR Link menu (7336.8) appears.
2
In the status area, select the target AUX bus to set.
To select AUX buses, set the [Num] parameter. The
specified number of AUX buses are selected from the
currently selected AUX bus.
3
In the group, select a group
(Link1 to Link12).
AUX buses configured in the same group form a link
group.
