135
Setting the border (menu)
1
In the M/E-1 >Key1 >Resizer menu (1115), press
[Resizer], turning it on.
2
In the group, press [Border/
Crop].
The Border/Crop menu (1115.1) appears.
3
Press [Border], turning it on.
4
Set the following parameters.
To apply color to a border
1
In the group, press [Flat Color].
2
Set the following parameters.
To soften the inner edge of a border
1
Press [Border Soft].
2
Set the following parameter.
To add a beveled light edge
1
In the group, press [Beveled Light
Edge].
2
Set the following parameters.
3
If setting the softness of the border, press [Border
Soft], turning it on.
4
Set the following parameters.
To add a beveled color edge
1
In the group, press [Beveled Color
Edge].
2
In the group, select the edges for
adjustment.
Select [Top], [Left], [Right], or [Bottom]. To adjust all
four edges simultaneously, press [All].
3
Set the following parameters.
4
If setting the softness of the border, press [Border
Soft], turning it on.
5
Set the following parameters.
Setting the border (device control block)
You can adjust the border width of the top/bottom/left/
right edges in the device control block (trackball).
The [BDR/CROP] button must be assigned to the
operation buttons beforehand in the Setup menu
(see
page 413) .
1
Enable the resizer as described in steps 1 to 3 in
“Reducing, enlarging, rotating, and moving keys
(device control block)” (page 132)
.
No. Parameter Adjustment
1 H Simultaneously adjust border width
of left and right edges
2 V Simultaneously adjust border width
of top and bottom edges
3 All Simultaneously adjust border width
on all edges
4 Density Border density
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
No. Parameter Adjustment
1 Inner Soft Softness of inner edge of border
No. Parameter Adjustment
1 Top Position of top side
2 Left Position of left side
3 Right Position of right side
4 Bottom Position of bottom side
5 All Position of all four sides
No. Parameter Adjustment
1 Inner Soft Softness of inner edge of border
2 Bound Soft Softness of border boundary
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
No. Parameter Adjustment
1 Inner Soft Softness of inner edge of border
2 Bound Soft Softness of border boundary
Note
No. Parameter Adjustment
