a) 1, 3, 5, 7, 9, 11, 13, 15: R1 to R8 (red tally)
2, 4, 6, 8, 10, 12, 14, 16: G1 to G8 (green tally)
17 to 24: Y1 to Y8 (yellow tally, NS-Bus only)
7
Press [Execute].
Deleting Parallel Tally
1
In the Engineering Setup >Router/Tally >Parallel
Tally menu (7366), select the parallel tally.
2
Press [Clear].
Serial Tally Settings
You can configure the tally type, data size, and source
address for two serial tally ports on a system interface unit
(SIU). You can also specify a port number for a network
connection to control tally information via a network.
If using a network port, configuration of the SIU utility
connector is required. For details, refer to the ICP-X7000
Installation Manual.
Configuring/Modifying Serial Tally
1
In the of the Engineering Setup
>Router/Tally >Serial Tally menu (7367), select the
target port to set.
2
In the group, select the tally group.
3
In the group, select the tally types.
Up to four tally types can be selected.
The selectable tally types depend on the setting
selected in step
2 .
4
In the group, select the data size.
128 Bit: 128 bits
256 Bit: 256 bits
5
To configure a network port, select [Port].
Enter the network port number using the numeric
keypad window, then press [Enter].
Correct operation may not occur, depending on the
port.
For the serial tally network port, port number “2020”
is recommended for [Port1], and “2021” is
recommended for [Port2]. For details, consult your
Sony service or sales representative.
No. Parameter Adjustment
3 Type Tally type a)
