272
To set a test sphere
1
In the Light 1 menu (4156.3), press [Test Sphere],
turning it on.
A test sphere effect appears on the surface of the
image.
2
Set the following parameter.
a) Light appears from Z direction. –100.00 indicates light that is
furthest away, and +100.00 indicates light that is closest.
0.00 indicates the whole image is lit like a flat effect.
To set the illuminated area
In the group of the Light 1 menu (4156.3),
select one of the following.
FRGD: The light strikes the image foreground.
BKGD: The light strikes the image background.
Both: The light strikes both the image foreground and
background.
For details about the illuminated area, see “Selecting the
illuminated area” (page 269).
• When [Multiply] is selected in the
Mode> group of the Light Color Adjust menu (4156.4)
(see page 273) , the lighting effect is not applied to the
background, even if [BKGD] or [Both] is selected.
• When [Brilliancy] is set to 100.0 in the
group of the Light Color Adjust menu (4156.4) (see
page 273) , the lighting effect is not applied to the
background, even if [BKGD] or [Both] is selected.
• When the global effect combiner is set to [Mix] or
[Depth], the lighting effect is not applied to the
background, even if [BKGD] or [Both] is selected.
To set Surface Flat
In the Light 1 menu (4156.3), press [Surface Flat], turning
it on.
When [Non Linear] is selected in the
group of the Spot Lighting menu (4156), only the part of
the surface being illuminated by light from the currently
set light source has the state as if [Flat] had been selected.
To set the shape of the lighting
1
In the Light 1 menu (4156.3), press [Shape], turning it
on.
2
Set the following parameters.
a) See page 269 .
b) 0 is a round shape, and 100 is the shape of the pattern. Smaller values
make the pattern more rounded.
c) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction.
To rotate the shape pattern
1
In the Light 1 menu (4156.3), press [Shape Speed],
turning it on.
When [Shape] is selected, the display of the 5th
parameter changes.
2
Set the following parameters.
a) –100.00 is four rotations per second in the counterclockwise
direction, and +100.00 is four rotations per second in the clockwise
direction. 0.00 stops the rotation.
To change the light to a ring shape
When [Parallel] or [Whole] is selected in the
group, the Ring parameter cannot be set if Shape is
disabled.
1
In the Light 1 menu (4156.3), press [Ring].
2
Set the following parameters.
a) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction.
There is no [Radius] parameter setting when [Line] is
selected in the group.
No. Parameter Adjustment
5 Amp Light separation distance
a)
Notes
No. Parameter Adjustment
1 Shape Ptn Shape pattern
a)
2 Size Shape size
3 Deform Amount of shape deformation
b)
4 Soft Softness of shape pattern
5 Angle Angle of shape pattern rotation
c)
No. Parameter Adjustment
5 Speed Rotation speed and direction a)
Note
No. Parameter Adjustment
1 Offset Offset from center position (radius)
2 Radius Radius of ring
3 Angle Rotation angle of ring
a)
Note
