241
You can adjust the size of the pattern using the [Size]
parameter.
To set the pattern size and position
1
In the Wipe Crop menu (4116), press [Position/Size].
2
Set the following parameters.
When pattern number 304 is selected, the
group effect varies according to the [Size] parameter
setting.
To invert the regions with video signal inserted
and not inserted
In the DME >Edge >Wipe Crop menu (4116), press
[Invert], turning it on.
To set the radius of pattern corners
You can set the radius of the four corners when wipe
pattern 304 is selected.
This setting is available only when the signal format is
1080i.
1
In the Wipe Crop menu (4116), press [Radius].
2
Set the following parameter.
Setting the aspect ratio of the wipe crop
pattern (Aspect)
1
In the Wipe Crop menu (4116), press [Aspect].
2
Set the following parameters.
a) When a minus value is specified, the picture is extended in the
vertical direction. When a plus value is specified, the picture is
extended in the horizontal direction.
Rotating the wipe crop pattern (Rotation)
1
In the
(4116), select one of the following.
Angle:
Incline the pattern at a fixed angle.
Speed:
Rotate the pattern at a set speed.
2
Depending on the selection in step
1
, set the following
parameters.
When [Angle] is selected
a) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction. 0.00 is no rotation.
When [Speed] is selected
a) –100.00 is four rotations per second in counterclockwise direction.
+100.00 is four rotations per second in clockwise direction. 0.00 is in
stationary state.
Applying modulation to the wipe crop
pattern (Modulation)
1
In the
(4116), select one of the following.
H:
Modulate the pattern to apply waving in the
horizontal direction.
V:
Modulate the pattern to apply waving in the vertical
direction.
2
Set the following parameters.
Replicating the wipe crop pattern (Multi)
1
In the Wipe Crop menu (4116), press [Multi], turning
it on.
2
Set the following parameters.
No.
Parameter
Adjustment
1
H
Horizontal position
2
V
Vertical position
3
Size
Pattern size
5
Pattern
Pattern number
Note
Note
No.
Parameter
Adjustment
1
Radius
Corner radius
No.
Parameter
Adjustment
1
Aspect
Aspect ratio
a)
No.
Parameter
Adjustment
1
Angle
Rotation angle of pattern
a)
No.
Parameter
Adjustment
1
Speed
Rotation speed of pattern
a)
No.
Parameter
Adjustment
1
Amplitude
Amplitude of modulation
2
Frequency
Frequency of modulation
3
Speed
Speed of ripples
No.
Parameter
Adjustment
1
H Multi
Number of repetitions of pattern
horizontally
