206
• Settings are linked with the Engineering Setup
>Switcher >Config >PGM Config menu (7331.2).
• Cannot be configured when the Engineering Setup
>Switcher >Config >PGM Config menu (7331.2) is
locked or when [Recall M/E Config] is disabled in the
Engineering Setup >Switcher >Config menu (7331).
1
Open the M/E-1 >Misc >Key Assign menu (1175).
The current key assignment is shown in the status area.
2
Change the key assignment in the “Key Enable” field.
Keys recalled in a snapshot recall
If a snapshot is recalled independently on the main bank or
sub bank, this only retrieves the settings for the key
assigned to the recalled bank. For example, if key 1 and
key 2 are assigned on the main bank, and key 3 and key 4
are assigned on the sub bank, then if you recall a snapshot
on the main bank, this only retrieves the settings for key 1
and key 2, and the state of key 3 and key 4 assigned on the
sub bank is not affected.
Assigning sub bank preview output to
buttons
The “Sub Preview” utility command on each switcher
bank can be assigned to the following buttons.
• Cross-point buttons on the cross-point control block in
utility/shotbox mode
• Memory recall buttons in the utility/shotbox control
block
• User preference buttons in the menu panel
For details, see “Settings Relating to Button Assignment”
(page 421).
Setting the matrix size
When using a router, if the matrix size is set to [128×128],
it is not possible to control the utility 3 bus on the S-Bus/
NS-Bus.
When using Multi Program 2, select a size other than
[128×128] in the
Setup >Router/Tally >Router menu (7361).
For details, see “Assigning Switcher Inputs/Outputs to S-
Bus/NS-Bus Space” (page 487).
If [136×138] is selected in the
bus number of the DME Key bus is used as the bus number
of the utility 3 bus.
Making settings for keyframe timeline
operation
To assign a sub bank region to a region selection
button in the numeric keypad control block
In the Engineering Setup >Panel >Config >10 Key Region
Assign menu (7321.7), assign sub bank region to the
region selection button in the numeric keypad control
block.
To select a region or reference region using the
menu
During snapshot or keyframe operations, you can select a
region (including sub bank) in the Key Frame >Region
Select menu (6117).
This is convenient for selecting some of the regions
assigned to the numeric keypad control block or changing
the reference region.
For details, see “Recalling regions to edit (menu)”
(page 309).
To assign regions shown in the timeline menu
The timeline and other information is displayed for each
region assigned in the numeric keypad control block in the
Key Frame >Time Line menu (6111).
You can set the display method in the Key Frame
>Timeline Assign menu (6115).
For details, see “Timeline Menu Display Settings”
(page 306).
Notes
No.
Bus (Standard)
Bus (MP2)
70
M/E-1 DME Key
M/E-1 Utility3
85
M/E-2 DME Key
M/E-2 Utility3
100
M/E-3 DME Key
M/E-3 Utility3
115
P/P DME Key
P/P Utility3
No.
Bus (Standard)
Bus (MP2)
