430
Configuring file list sharing
You can configure sharing of the same file list, for
example, when the same device is connected to more than
one port.
Only ports to which a disk recorder (video disk
communications protocol, Odetics protocol) or Extended
VTR has been assigned are enabled.
1
In the Engineering Setup >Panel >Device Interface
>Device Assign menu (7325.4), select the target port
to set.
2
Select the device (DEV CH1 to DEV CH12) for
sharing the file list.
3
Press [Same File List Set].
4
Repeat steps
1
to
3
as required to select other devices
for sharing the file list.
Setting the AUX Bus Override
Operation Mode
Set the operation mode when the trigger type is “Rising
Edge” or “Falling Edge,” and “Aux ? O’ride Src ??” is
selected as the GPI input action.
In the
Engineering Setup >Panel >Device Interface menu (7325),
select one of the following.
Momentary:
On an input pulse rising (falling) edge, the
input of the selected AUX bus is used, and on a falling
(rising) edge it returns to the original cross-point.
Latch:
On an input pulse rising (falling) edge, the input of
the selected AUX bus is used, and it does not return to
the original cross-point even on a falling (rising) edge.
This setting is enabled when AUX bus override is selected
as the SIU (DCU function) GPI input
Settings Relating to
Operation
Setting the On-Air Tally
This sets the high tally state reflected on the control panel.
1
In the Engineering Setup >Panel >Operation menu
(7326), press [Button Tally].
The Button Tally menu (7326.9) appears.
2
In the
[R1] to [R8]:
Reflect the tally state of the tally groups
1 to 8.
Independ:
Reflect the tally state of the switcher only.
3
Press [Execute].
Setting the Transition Rate Display
Mode
This sets the transition rate display mode to the number of
frames or to a timecode.
In the
Setup >Panel >Operation menu (7326), select one of the
following.
Frame:
Display as number of frames.
Timecode:
Display as timecode (SS:FF).
Setting the Main Fader Lever
This sets which of the fader levers is the main lever for
operation on the background A bus when using split
faders.
If the conditions for using split faders are not satisfied,
only the main fader lever can be operated.
In the
>Panel >Operation menu (7326), select one of the
following.
Left:
Set the left fader lever as the main fader lever.
Right:
Set the right fader lever as the main fader lever.
Note
No.
Parameter
Adjustment
2
File List
Device
