431
Configuring Settings Relating to
Effects
Setting functions used in keyframe effect
operations
In the Engineering Setup >Panel >Operation menu (7326),
press [Effect Mode] to open the Effect Mode menu
(7326.2).
Configure each function, as required.
Setting the first keyframe state when recalling an
effect
In the group, select one of the following.
Recall: The first keyframe is not reproduced.
Recall&Rewind: The first keyframe is reproduced.
Disabling the [EDIT ENBL] button when recalling
an effect
Press [Edit Enable Auto Off], turning it on.
If an effect is recalled when the [EDIT ENBL] button is lit,
the [EDIT ENBL] button is automatically disabled.
Inserting the first keyframe automatically
Press [1st KF Auto Insert], turning it on.
When an empty register is recalled, the state at that point is
automatically inserted as the first keyframe.
Setting the operation mode when the [RUN]
button is pressed during keyframe effect
execution
In the group, select one of the following.
Continue: Continue the effect.
Cancel: Cancel the effect, and return to the previous state.
Setting auto save for an effect
Press [Effect Auto Save], turning it on.
When an effect is recalled after effect editing, the edited
effect is automatically saved.
Setting the default value of keyframe duration
Press [Default KF Duration], then enter the default value
using the numeric keypad window.
Setting the first keyframe when rewind is
executed
For P-Bus, GPI, DDR/VTR, and macro timeline
operations, you can set to execute the first keyframe when
rewind is executed.
When enabled and an effect is executed by pressing the
[RUN] button, the first keyframe action is not executed.
In the group of the Engineering Setup
>Panel >Operation >Effect Mode menu (7326.2), select
the target to set.
GPI: GPI timeline
P-Bus: P-Bus timeline
DDR/VTR: VTR/disk recorder timeline
Macro: Macro timeline
Setting Source Names and
Destination Names
You set the source and destination names to use in the
control panel.
It is necessary to set the group number of the S-Bus
description name or NS-Bus alias name beforehand
(see
page 488) .
1
In the group of the Engineering
Setup >Panel >Operation menu (7326), select the
name to use.
Sw’er Local: Source name set on the switcher, and
fixed bus name
S-Bus Descript: Description name set in the router
(S-Bus only)
S-Bus Type+Num: Type+Num name set in the router
(S-Bus only)
NS-Bus Alias: Alias name set in the system controller
(NS-Bus only)
2
In the group, select the display
method.
Auto: Four characters per line, up to four lines
2 Characters: First two characters displayed on one
line
4 Characters: First four characters displayed on one
line
• When [S-Bus Type+Num] is selected in step 1 , the
first eight characters are displayed on two lines. The
display method cannot be set.
• Line breaks in names are valid only when [Auto] is
selected.
• Up to two lines are displayed when the display mode
(see page 438) is set to split display.
Enabling the description name/alias name
link function
When the link function is enabled, you can replace a
source name set on the switcher with an S-Bus description
Note
Note
Notes
