428
Setting names to display in memory recall
buttons
You can set the display of names on buttons when menu
shortcuts or utility commands are assigned to the memory
recall buttons.
When a macro register is assigned, the names specified in
the Macro menu are displayed on the memory recall
buttons. When a shotbox register is assigned, the names
specified in the Shotbox menu are displayed on the
memory recall buttons.
1
In the Engineering Setup >Panel >Prefs/Utility
>Utility Module Assign menu (7324.1), select the
target button to set.
2
Press [Name].
3
Enter a name of up to 8 characters in the keyboard
window, and press [Enter].
Setting the transition rate target to display
on memory recall buttons
This sets the memory recall button assignments in
transition rate display mode.
1
In the Engineering Setup >Panel >Prefs/Utility
>Utility Module Assign menu (7324.1), press [Trans
Rate Mode Assign].
The Trans Rate Mode Assign menu (7324.3) appears.
2
Select the target button to set.
3
Select the transition rate to assign.
4
Press [Set].
To release the assignment
Select the target button to release, then press [Clear].
Assigning Functions to Cross-Point
Buttons of the Cross-Point Control
Block
You can assign functions to the cross-point buttons of the
cross-point control block (utility/shotbox mode).
1
In the Engineering Setup >Panel >Prefs/Utility menu
(7324), press [Xpt Module Assign].
The Xpt Module Assign menu (7324.2) appears.
2
Select the target button to set.
3
In the
Menu Shortcut:
Assign a frequently used menu to be
recalled (menu shortcut).
Utility Command:
Assign a function setting (utility
command).
Macro Recall:
Assign a macro register recall.
Shotbox Recall:
Assign a shotbox register recall.
4
Perform the following operations, according to the
selection in step
3
.
When [Menu Shortcut] is selected:
When a cross-
point button on the cross-point control block is
blinking, display the shortcut menu. Press the
target button to set to assign a shortcut. When
finished, press [Menu Shortcut] again.
When [Utility Command] is selected:
Select a
command to assign in the list on the right side of
the status area.
a) For “DCU GPI Test Fire” only
When [Macro Recall] is selected:
Select a macro
register to assign in the list on the right side of the
status area.
When [Shotbox Recall] is selected:
Select a shotbox
register to assign in the list on the right side of the
status area.
5
Press [Action Set].
When [Menu Shortcut] is selected in step
3
, it is not
necessary to press [Action Set].
To release the assignment
Select the target button to release, then press [Clear].
To display the register name in the status area list
When [Macro Recall] or [Shotbox Recall] is selected, you
can change the register number display to the register
name.
Note
No.
Parameter
Adjustment
1
Bank
Bank selection
2
Button No
Button selection
No.
Parameter
Adjustment
3
Command
Utility command selection
4
a)
GPI No
GPI number
No.
Parameter
Adjustment
3
Macro
Macro register selection
No.
Parameter
Adjustment
3
Shotbox
Shotbox register selection
