445
1 bus (regardless of constraints, such as M/E
configuration) when the switcher signal format is
3840×2160P or 1080P.
• The extended re-entry settings are common to all
switcher banks.
• Extended re-entry for keyers is available only when the
switcher signal format is 3840×2160P or 1080P.
• A delay may occur in the re-entry signal when extended
re-entry is enabled.
If a delay occurs, the ancillary data is disabled, even
when through mode is set.
• Recursive re-entry may cause problems in the video.
• The selection order of re-entry signals affects the
number of lines by which the output signal is lowered.
• On the XVS-8000, extended re-entry for keys is not
supported on the key 3 and key 4 buses when the signal
format is 3840×2160P.
However, when using dedicated inputs
(see page 447)
and extended re-entry for keys is enabled, re-entry
signals can always be selected on the key 3 and key 4
buses.
1
Open the Engineering Setup >Switcher >Config menu
(7331).
2
To enable extended re-entry for switcher banks, press
[M/E] in the group, turning it
on.
3
To enable extended re-entry for keyers, press [Keyer]
in the group, turning it on.
Settings Relating to
Signal Inputs
Configures settings for primary inputs.
The following input connector boards can be installed in
the XVS-9000/8000/7000/6000.
• XVS-9000
• XVS-8000/7000/6000
a) Interface configured in the Engineering Setup >System >Network Config
>Net I/F Protocol menu (7311.3)
The maximum number of inputs on the XVS-9000 is 160
(80 for 4K format), on the XVS-8000 is 160 (40 for 4K
format), on the XVS-7000 is 112 (28 for 4K format), and
on the XVS-6000 is 64 (16 for 4K format).
59.94 (2×) format input signals are supported on the
XKS-S8110 SDI Input Connector Board only.
Network connector board restrictions
Only the following interface and signal format inputs are
supported, depending on the board.
Notes
Input connector board Interface
XKS-S9112 12G-SDI Input Board SDI
XKS-C9111 100G IP Input Board ST2110
XKS-C9111N NMI Input Board NMI
XKS-C9121 100G IP Input and Output
Board ST2110
XKS-C9121N NMI Input and Output
Board NMI
Input connector board Interface
XKS-S8110 SDI Input Connector Board SDI
XKS-S8111 SDI Input and FC Connector
Board SDI
XKS-S8112 12G-SDI Input Board SDI
XKS-T8110 IP Input Connector Board NMI
XKS-Q8111 QSFP IP Input Connector
Board NMI/ST2110
a)
XKS-C8111 100G IP Input Board ST2110
Note
Board Interface Signal formats
XKS-T8110 NMI • 3840×2160P 2SI (Level A)
a)
• 1080P (Level A) b)
• 1080i
XKS-Q8111 NMI • 3840×2160P 2SI (Level A)
a)
• 1080P (Level A)
b)
• 1080i
ST2110 • 1080i
b)
