38
f Display
Displays the name of parameter items and the setting
value.
g Adjustment knobs
These buttons adjust the parameters of items selected using
the setting buttons.
Button name Description
OVERRIDE Assigns a DME channel assigned
to another key/bus to the currently
selected key (override function).
Press and hold the [OVERRIDE]
button and press the target DME
channel button to change the
assignment.
TRACE When a DME channel is assigned
to another key, this switches the
delegation to the key assigned with
the DME channel (trace function).
Press and hold the [TRACE] button
and press the target DME channel
button to switch the delegation.
MON (monitor) • Assigns a DME channel output to
the monitor signal.
Press and hold the [MON] button
and press the target DME
channel selection button to set it.
• You can check the monitor signal
assignment status by pressing
the [MON] button by itself.
Lit amber:
Assignable DME channel.
Lit green:
Currently assigned DME channel.
PROC KEY
(processed key) Press the [PROC KEY], turning it
on amber, to enable selection of a
processed key signal as a re-entry
signal (PROC V, PROC K) on a
bank (M/E-1 to M/E-5, PGM/PST).
FM FEED (frame
memory feed) Pressing the [FM FEED] button,
turning it on amber momentarily,
selects the processed key signal on
the frame memory source 1 and 2
buses. The [PROC KEY] button is lit
amber simultaneously.
SHOW KEY Displays the processed key source
signal on the specified output (edit
preview or image creation bank
preview) while the [SHOW KEY]
button is pressed (or for a preset
time) (show key function).
The show key function output and
preset time are configured in the
Setup menu.
For details, see “Setting Show Key”
(page 470).
AUTO DELEG (auto
delegation) Switches the key control block
delegation selection in conjunction
with buttons on the following control
blocks.
• Transition control block: [KEY1] to
[KEY8] buttons
• Cross-point pad on the cross-
point control block: Key 1 to 8 bus
delegation buttons [KEY1] to
[KEY8]
• 1st row on cross-point control
block (key/AUX bus delegation
mode): [KEY1] to [KEY8] buttons
• Memory recall section on the
Flexi Pad control block (key
operation mode): [KEY1] to
[KEY8] buttons
• Key fader control block: Key
delegation buttons
MORE • When there are more than six
parameters, this button is lit
amber.
• Press the [MORE] button, turning
it on green, to display the 6th and
subsequent parameters.
Button name Description
