529
a) You can change the M/E banks that are to be disabled in the Engineering
Setup >Switcher >Config >Logical M/E Assign menu (7331.5).
b) When a dedicated input is used, signals configured using the Engineering
Setup >Switcher >Input >Dedicated Input Assign menu (7332.10) can also
be selected.
Sub key restrictions
When using the XKS-8210 (for XVS-9000/8000) or
XKS-7210 (for XVS-7000/6000) Mix Effect Board, key 3
and key 4 function as sub keys in 3840×2160P signal
format. For sub keys, the following function and settings
restrictions apply.
You can set the sub key mode in the Setup menu
.
Resource Sharing
Configuration Operations
Resource sharing is configured using the “Resource Share
Setup” application on a computer connected to the
switcher control station (SCS) via network connection.
For details about computer connection, refer to the
ICP-X7000 Installation Manual.
You can save and recall resource sharing configuration
data between the switcher system and a computer using the
file manager.
For details, see “File Manager” (page 536).
Preparations
Launch a browser on the computer, and access Resource
Share Setup.
1
Access Resource Share Setup.
Enter the following URL in the browser.
For encrypted communications:
“https://LAN2 IP address on SCS/xwm/rs-setup/”
For unencrypted communications:
“http://LAN2 IP address on SCS/xwm/rs-setup/”
The Resource Share Setup login screen appears.
2
Enter the administrator user name and password, and
click/tap [Login].
The Resource Share Setup page appears.
For details about the user name and password, consult
your Sony service or sales representative.
Safe titles
• Outputs with active area of
4096×2160 not supported
• In SQD, [Grid] not supported
Color backgrounds
• Color background 2 not supported
• In SQD, [Multi], [Pairing], and
supported
Multi viewers
In SQD, screen split by 10, 13, and 16
not supported
Note
Item
Restrictions
Transitions
Independent key transitions only
supported
However, the following settings are not
supported.
• Wipe transition type
• DME wipe transition type
Key settings
Luminance key and linear key only
supported
However, the following settings are not
supported.
• [Filter] parameter
• [Key Position]
• [Mix Color] in the
• Edge
• Mask
• Blink
Key priority
Priority settings not supported
(Key 4 and key 3 are fixed at the top, in
that order, and key 1 and key 2 priority
can be configured below key 3.)
Resizer
Resizer not supported
Key preview/Show
key
Key 3 only supported when the sub key
is set to [Key3 + Key PVW].
DMEs
Functions relating to DMEs not
supported
Item
Restrictions
Note
Note
