a) Different mix effect boards (XKS-8210/XKS-7210 or XKS-8215/

XKS-7215) cannot be installed in a single switcher at the same time.
Also, on the XVS-6000, only the XKS-7210 can be installed. The
XKS-7215 is not supported.

b) When using the XKS-8215, five M/E banks is the maximum only when all

the input/output connector boards are SDI connector boards. Four M/E
banks is the maximum when one or more network connector boards is
installed.

c) When a dedicated input is used, signals configured using the Engineering

Setup >Switcher >Input >Dedicated Input Assign menu (7332.10) can also
be selected.

Internal format
converters

Configurable only when
resource sharing enabled

Max. 16 channels
(Max. 4 channels for 4K
format)
• FC1 to FC16

configurable for input
use or output use

Max. 16 channels
(Max. 4 channels for 4K
format)
• FC1 to FC8

configurable for input
use or output use, FC9
to FC16 reserved for
output use

Max. 16 channels
(Max. 4 channels for 4K
format)
• FC1 to FC16

configurable for input
use or output use

Input/output
format
converter

• Input format converter
• Output format converter

• Input format converter
• P/I converter

GPI outputs

Alarm output

–

Keys

8 keys per switcher bank
(Max. 4 keys for 4K
format)

8 keys per switcher bank
(Max. 2 keys + 2 sub keys
for 4K format)

No restrictions on
selectable signals on key
3 and key 4 in
3840×2160P format

Only primary input
(excluding XKS-T8110
input signals), black,
white, and color
background signals can
be selected on key 3 and
key 4 in 3840×2160P
format

No restrictions on
selectable signals on key
3 and key 4 in
3840×2160P format

Item

Switcher

XVS-9000

XVS-8000

XVS-7000

XVS-6000
