394
3
In the status area, select the target slot in which the
board is installed.
4
Enable NMOS.
Press [NMOS], turning it on.
When LSM is enabled in the IP Address menu
(7311.2), [NMOS] turns off and NMOS of the target
board becomes disabled.
5
Enable or disable obtaining an address automatically.
To disable, press [RDS Discovery], turning it off.
To enable, press [RDS Discovery], turning it on, and
skip to step
10 .
6
In the group, press [IP Address], and
set the IP address of the primary RDS server.
Enter the IP address using the keyboard window, then
press [Enter].
7
In the group, press [Port], and set the
port number of the primary RDS server.
Enter the port number using the numeric keypad
window, then press [Enter].
8
In the group, press [IP Address],
and set the IP address of the secondary RDS server.
Enter the IP address using the keyboard window, then
press [Enter].
9
In the group, press [Port], and set
the port number of the secondary RDS server.
Enter the port number using the numeric keypad
window, then press [Enter].
10
Repeat steps 3 to 9 as required.
11
Press [Execute].
12
Check the message, then press [Yes].
Setting the Network Interface
Protocol
On the XVS-8000/7000/6000 with an XKS-Q8111/
XKS-Q8166 installed, you can set the network interface
protocol. NMI (Networked Media Interface) and ST2110
(SMPTE ST 2110 compliant) protocols can be selected.
• On the XVS-9000, the protocol cannot be set. Only the
following protocols are supported on each network
connector board.
- XKS-C9111/XKS-C9121: ST2110
- XKS-C9111N/XKS-C9121N: NMI
• On the XVS-8000/7000/6000, the protocol cannot be set
when the following network connector boards are
installed. Only the following protocols are supported on
each network connector board.
- XKS-T8110/XKS-T8165: NMI
- XKS-C8111/XKS-C8166: ST2110
• The protocol setting is common to all slots in which an
XKS-Q8111/XKS-Q8166 is installed. If different
protocols are displayed among the slots, reconfigure the
protocol setting.
Network connector boards that use different protocols
cannot be installed in a switcher at the same time.
1
In the Engineering Setup >System >Network Config
menu (7311), press [Net I/F Protocol].
The Net I/F Protocol menu (7311.3) appears.
2
In the group, select the target switcher to set.
3
In the status area, select a slot.
4
In the group, select one of the
following.
NMI: Set to NMI.
ST2110: Set to SMPTE ST 2110 compliant.
The selected protocol is displayed for all slots in which
an XKS-Q8111/XKS-Q8166 is installed.
5
Press [Execute].
6
Check the message, then press [Yes].
Note
Notes
