Chapter
19
441
Switcher Setup
Settings Relating to
Switcher Configuration
Adjusting the Reference Phase
This adjusts the switcher internal reference phase.
In the Engineering Setup >Switcher >Config menu (7331),
set the following parameter.
Specifying the Video Switching
Timing
1
In the Engineering Setup >Switcher >Config menu
(7331), press [Switching Timing].
The Switching Timing menu (7331.8) appears.
2
Select one of the following.
Any: Not specified
Field 1: Field 1
Field 2: Field 2
Fixed to [Field 1] when the signal format is
3840×2160PsF or 1080PsF, and fixed to [Any] when
720P.
Setting the Operation Mode
This sets the output signal configuration for each bank.
1
Open the Engineering Setup >Switcher >Config menu
(7331).
2
In the status area, select the target switcher bank to set.
3
In the group, select the operation mode.
Standard: Standard mode
Multi Program: Multi-program mode
DSK: DSK mode (PGM/PST only)
About the operation mode
• Standard mode: Fix the output signal configuration for
the maximum of four outputs (Out1 to 4) of the M/E and
PGM/PST banks as follows.
- Out1: Program output
- Out2: Preview output
- Out3: Clean output
- Out4: Key preview output
1)
• Multi-program mode: Increase the number of M/E or
PGM/PST program systems, and assign one of the
following to up to six outputs (Out1 to 6) (M/E Output
Assign).
- Program outputs 1 to 4
- Preview output
- Key preview outputs
1)
1 and 2
- Clean output
Further, you can change the combination of signals from
which the program output is configured (PGM Config).
• DSK mode: Treats PGM/PSTs as DSKs by assigning
one of the Out1 to Out6 program outputs of M/E-1 to
M/E-5 to the background. You can change the signals
that make up the program output and key preview
output
1)
using PGM Config and K-PVW Config.
1) For the key preview output, you can select either video mode (background
and key) or key mode (key only), and select the background and key (K-
PVW Config).
• When Multi-program mode is selected, two or more
transition type selection buttons may be lit on the
transition control block. Also, more than one
group button may be selected in the
Misc >Transition menu of each M/E and PGM/PST
bank.
• In 4K format, up to four outputs (Out1 to Out4) are
available on each switcher bank in multi-program mode.
• In 4K format, the outputs in DSK mode have the
following configuration.
- Out1: Program output 1
No. Parameter Adjustment
3 Phase Switcher internal reference phase
Note
Notes
