Page 151
151
2
Press [Spiral], turning it on.
3
Set the following parameters.
Wipe patterns and supported modifiers
Yes: Available, No: Not available
a) Pattern numbers 1 to 16, 19, and 20 are not available.
b) Pattern numbers 300 to 303 are not available.
c) Pattern numbers 100 to 103, 150, 151, 516, 518, 604, and 606 are not
available.
d) Pattern numbers 1 to 8, 17, and 18 are not available.
e) Pattern numbers 220 to 223 are not available.
f) Pattern numbers 19 and 20 are not available.
g) Pattern numbers 21, 23, and 24 are available.
h) Pattern numbers 21 and 23 are available.
Wipe Modify Clear
Press [Default Recall] at the lower left of the menu display,
turning it on, then press the VF5 button ([Wipe]) to return
the wipe settings to their initial status.
For details about initial status, see “Power-On (Startup)
State Selection” (page 399).
No.
Parameter
Adjustment
1
Magnitude
Size and direction of the spiral
• A value of –100.00 represents
the maximum movement in the
counterclockwise direction.
• A value of +100.00 represents
the maximum movement in the
clockwise direction.
2
Wave
Speed
Speed of the lateral waves
• Negative values set the speed
from the left.
• Positive values set the speed
from the right.
Modifiers
Type of wipe
Standard Enhanced Rotary Mosaic Random/
diamond
dust
Direction
Yes
Yes
Yes
Yes
Yes
Split
Yes
Yes
No
Yes
Yes
Edge
Yes
Yes
Yes
Yes
Yes
Positioner
Yes
a)
Yes
b)
Yes
c)
No
No
Rotation
Yes
Yes
Yes
c)
No
No
Aspect
Yes
d)
Yes
No
No
No
Multi
Yes
Yes
Yes
Yes
e)
No
Pairing
Yes
f)
Yes
No
No
No
Modulation
(H, V)
Yes
Yes
Yes
No
No
Modulation
(Fringe)
No
g)
Yes
No
No
No
Spring
No
g)
Yes
No
No
No
Spiral
No
h)
Yes
No
No
No
