Overview
Introduction
This manual describes the functions and operation of the
XVS-9000/8000/7000/6000 Multi Format Switcher
system.
It describes picture creation and configuration settings
using the ICP-X7000 Integrated Control Panel.
System configuration devices
The principal components of the XVS-9000/8000/7000/
6000 system and the terms used in this manual are as
follows.
Signal format notation
The signal formats in the menu and this manual are
denoted as given below.
a) SMPTE ST 425-5/SMPTE ST 2082-1, Level A, 2-sample interleave
division (2SI) and square division (SQD) compliant.
b) Square division (SQD) compliant.
c) SMPTE ST 425-1, Level A compliant.
3840×2160PsF format
In this format, 3840×2160 images are subdivided into four
and are transferred as four 1080PsF format signals.
Unless stated otherwise in this document, the term “4K
format” includes the 3840×2160PsF format.
About screenshots and illustrations
The display of operation buttons and menu screens vary,
depending on the system configuration.
Configuration
device Terms used in this manual
XVS-9000
Multi Format
Switcher • XVS-9000
• Switcher
• Multi format switcher
XVS-8000
Multi Format
Switcher • XVS-8000
• Switcher
• Multi format switcher
XVS-7000
Multi Format
Switcher • XVS-7000
• Switcher
• Multi format switcher
XVS-6000
Multi Format
Switcher • XVS-6000
• Switcher
• Multi format switcher
ICP-X7000
Integrated Control
Panel • ICP-X7000
• Control panel
• Integrated control panel
PWS-110SC1
Switcher Control
Station • PWS-110SC1
• SCS
• Switcher control station
PWS-100SC1
Switcher Control
Station • PWS-100SC1
• SCS
• Switcher control station
XKS-8475
DME Board • XKS-8475
• DME
• DME board
XKS-8470
HD DME Board • XKS-8470
• DME
• DME board
MKS-X7700
System Interface
Unit • MKS-X7700
• SIU
• System interface unit
MKS-X2700
System Interface
Unit • MKS-X2700
• SIU
• System interface unit
Format terms Format name
4K format 3840×2160P • 3840×2160P/59.94 a)
• 3840×2160P/50
a)
3840×2160PsF • 3840×2160PsF/29.97 b)
• 3840×2160PsF/25 b)
• 3840×2160PsF/24
b)
• 3840×2160PsF/23.98
b)
HD format 1080P • 1080P/59.94 c)
• 1080P/50
c)
1080PsF • 1080PsF/29.97
• 1080PsF/25
• 1080PsF/24
• 1080PsF/23.98
1080i • 1080i/59.94
• 1080i/50
720P • 720P/59.94
• 720P/50
