208
a) Key 2 to key 8 are common on both main and sub.
• Allow a transition to complete before carrying out main
and sub delegation switching.
• The sub bank background A bus (utility 2 bus) is shared
with wipe edge border fill. Making a change to one
affects the other.
• Even if the wipe border width is set to the same numeric
value for main and sub, the same image is not obtained.
Multi Program 2 Mode Restrictions
• The following functions are not available on the sub
bank.
- Data copy and swap
- Default recall (except for parametric recall)
- [AUTO PVW] button (button assigned with the “Auto
Preview” utility command)
- Split fader
• In Region Simul mode, the control target region on the
sub side is the same region as on the main side.
• In the following cases, a transition using the fader lever
may not be performed correctly:
- When the main and sub bus toggle modes are set
differently
- For a pattern limit, preset color mix, and so on
• For an Internal bus link or External bus link, the “Utility
2” bus cannot be selected.
• Show key and [MACRO ATTACH ENABLE] button
settings are common to main and sub.
• If a snapshot is recalled simultaneously for main and sub
or a keyframe is executed simultaneously for main and
sub, then the settings on the main bank are reflected in
the following shared data on main and sub.
- Keys
- M/E Config
- DME external video bus and utility 1 bus
• When a macro attachment is set on the DME utility 1 bus
or DME utility 2 bus, it is not possible to make separate
main and sub settings.
• When snapshots with different M/E Config settings are
recalled:
- If M/E Config data is not to be included in the snapshot
data, the current system settings are used for snapshot
reproduction.
- If M/E Config data is to be included in the snapshot
data, first M/E Config data is set and then other
snapshot data is recalled.
• The bus override function is only available on the
following buses:
- M/E-1 to M/E-5 Main BKGD A/B buses
- M/E-1 to M/E-5 Sub BKGD A/B buses (Util 2, Util 3
bus)
- P/P Main PGM/PST bus
- P/P Sub PGM/PST bus (Util 2, Util 3 bus)
• When a master snapshot or master timeline is executed
with a key assigned to both main and sub, it is uncertain
which data will be reflected.
• When recalling a master snapshot with different register
numbers for main and sub, the recall timing may differ
by one field or more between main and sub.
• The link state is maintained even when M/E Config is
changed. Set the link setting again, as required.
• Since key 2 to key 8 are shared between main and sub, if
the main and sub fader lever positions are different and
you move the fader lever, the video changes
instantaneously to the value of the most recently moved
fader lever.
• When the transition type for main or sub is set to preset
color mix, it is not possible to carry out independent key
transition operation (common to main and sub).
• Up to two background buses (on main and/or sub banks)
can set an image effect.
Snapshots Cross-point hold Utility 2 cannot be set • Utility 3 is added.
• BKGD A/B and Key1 cannot be set.
Item Main Sub
Notes
