Rockwell Automation Publication 2094-UM001H-EN-P - June 2013
27
Planning the Kinetix 6000 Drive System Installation
Chapter 2
Transformer Selection
The IAM module does not require an isolation transformer for three-phase input
power. However, a transformer can be required to match the voltage
requirements of the controller to the available service.
To size a transformer for the main AC power inputs, refer to the Kinetix 6000
power specifications in the Kinetix Servo Drives Technical Data, publication
.
For example, to size a transformer to the voltage requirements of a
2094-BC01-M01-S integrated axis module:
2094-BC01-M01-S = 6 kW continuous x 1.5 = 9.0 KVA transformer
AC Line Filter Selection
These AC line filters are available for your servo drive input power.
Table 8 - Kinetix 6000 (three-phase) AC Line Filter Selection
Refer to the Kinetix Motion Accessories Specifications Technical Data,
publicatio
IMPORTANT
If using an autotransformer, make sure that the phase to neutral/ground
voltages do not exceed the input voltage ratings of the drive.
IMPORTANT
Use a form factor of 1.5 for three-phase power (where form factor is used to
compensate for transformer, drive module, and motor losses, and to account
for utilization in the intermittent operating area of the torque speed curve).
Drive
Cat. No.
Voltage
Current
A @ 50 °C (122 °F)
Weight, approx
kg (lb)
AC Line Filter
Cat. No.
2094-AC05-MP5-S
500V AC
50/60 Hz
30
2.7 (5.9)
2090-XXLF-X330B
2094-AC05-M01-S
2094-AC09-M02-S
2094-AC16-M03-S
75
5.2 (11.4)
2090-XXLF-375
2094-AC32-M05-S
100
9.5 (20.9)
2090-XXLF-3100
2094-BC01-MP5-S
500V AC
50/60 Hz
30
2.7 (5.9)
2090-XXLF-X330B
2094-BC01-M01-S
2094-BC02-M02-S
2094-BC04-M03-S
75
5.2 (11.4)
2090-XXLF-375B
2094-BC07-M05-S
100
9.5 (20.9)
2090-XXLF-3100
