Table D-19. Database - F Type Datapoints
Data-
point
Name Module Atom Default Table
F084 Parameter Mod 0 Point 1 Designator
Parameter
PDA0 C106
5-11
F085 Parameter Mod 0 Point 2 Designator PDB0 C107
F086 Parameter Mod 0 Point 3 Designator PDC0 C108
F087 Parameter Mod 1 Point 1 Designator PDA1 C103
F088 Parameter Mod 1 Point 2 Designator PDB1 C104
F089 Parameter Mod 1 Point 3 Designator PDC1 C105
F090 Parameter Mod 2 Point 1 Designator PDA2 C142
F091 Parameter Mod 2 Point 2 Designator PDB2 C143
F092 Parameter Mod 2 Point 3 Designator PDC2 C144
F093 Parameter Mod 3 Point 1 Designator PDA3 C139
F094 Parameter Mod 3 Point 2 Designator PDB3 C140
F095 Parameter Mod 3 Point 3 Designator PDC3 C141
F096 Parameter Mod 4 Point 1 Designator PDA4 C178
F097 Parameter Mod 4 Point 2 Designator PDB4 C179
F098 Parameter Mod 4 Point 3 Designator PDC4 C180
F099 Parameter Mod 5 Point 1 Designator PDA5 C175
F100 Parameter Mod 5 Point 2 Designator PDB5 C176
F101 Parameter Mod 5 Point 3 Designator PDC5 C177
F102 Parameter Mod 6 Point 1 Designator PDA6 C214
F103 Parameter Mod 6 Point 2 Designator PDB6 C215
F104 Parameter Mod 6 Point 3 Designator PDC6 C216
F105 Parameter Mod 7 Point 1 Designator PDA7 C211
F106 Parameter Mod 7 Point 2 Designator PDB7 C212
F107 Parameter Mod 7 Point 3 Designator PDC7 C213
F176 Trend 0 Point Designator
Trend
TRP0
5-12
F177 Trend 1 Point Designator TRP1
F178 Trend 2 Point Designator TRP2
F179 Trend 3 Point Designator TRP3
F180 Trend 4 Point Designator TRP4
F181 Trend 5 Point Designator TRP5
F182 Trend 6 Point Designator TRP6
F183 Trend 7 Point Designator TRP7
F216 Tot Mod 0 Input Point Designator
Totalizer
TMPT0
5-13
F217 Tot Mod 1 Input Point Designator TMPT1
F218 Tot Mod 2 Input Point Designator TMPT2
F219 Tot Mod 3 Input Point Designator TMPT3
F220 Tot Mod 4 Input Point Designator TMPT4
F221 Tot Mod 5 Input Point Designator TMPT5
F222 Tot Mod 6 Input Point Designator TMPT6
F223 Tot Mod 7 Input Point Designator TMPT7
F248-
F251
Reserved Temporaries
BFTEMP
1 - 4
1 of 2
53MC5000 Process Control Station
D-38
