background image

Table 6-3. CS1 Single Loop CON0 Datapoints

Data-

point

Table

Module

Title and Function

De-

fault

AI0 - Process Variable

C256

5-4

AI0

Engineering Span - Enter a value, that when added to the
Engineering Zero value, will produce an upper range value in
engineering units that represents the PV transducer upper
range signal value.

100

C276

5-4

AI0

Engineering Zero - Enter a value that represents in
engineering units the PV transducer lower range signal value.

0

B269

5-4

AI0

Digital Filter Index - This is a first order filter that can be
applied to the PV transducer signal. See Table 5-4 for input
values.

3

L416

5-4

AI0

0-5 V Input - Enter a value that matches the signal voltage
range of the PV transducer. 1 = 0 - 5 V range; 0 = 1 - 5 V
range.

0

L440

5-4

AI0

Square Root Signal - It is used if the PV transducer is a
nonlinear differential pressure (DP) cell that provides a
squared signal value. 0 = input is already linear; 1 = square
root to restore linearization.

0

AI1 - Remote Setpoint (Is affected by the Setpoint Related Datapoints.)

L115

5-9

CON0

Remote Setpoint Enable - This datapoint is controlled by DI0.
When DI0 is a closed contact, this datapoint is set to 1 to
allow the modified Remote Setpoint to become the value
used as the control setpoint if the R/L push button is in
Remote.

0

C112

5-9

CON0

Remote Setpoint Bias (B1) - This datapoint and Remote
Setpoint Ratio (K1) allow the Remote Setpoint input to be
modified by the Setpoint Generator.
Setpoint = [Remote Setpoint X Ratio] + Bias
SP = [RSP X K1] + B1

The B1 and K1 datapoints are modified when the input signal
must be scaled to match the setpoint range desired.

0

C113

5-9

CON0

Remote Setpoint Ratio (K1) - See Remote Setpoint bias (B1)
above.

1

C257

5-4

AI1

Engineering Span - Enter a value, that when added to the
Engineering Zero value, will produce an upper range value in
engineering units that represents the Remote Setpoint upper
range signal value.

0

C277

5-4

AI1

Engineering Zero - Enter a value that represents in
engineering units the Remote Setpoint lower range signal
value.

0

B270

5-4

AI1

Digital Filter Index - This is a first order filter that can be
applied to the Remote Setpoint signal. See Table 5-4 for
input values.

3

L417

5-4

AI1

0-5 V Input - Enter a value that matches the signal voltage
range of the Remote Setpoint signal. 1 = 0 - 5 V input range;
0 = 1 - 5 V input range.

0

1 of 5

Section 6. CS1 - Single Loop Controller

6-5
