Table 10-3. CS5 Ratio Automatic/Manual Station Datapoints

Data-

point

Table

Module

Title and Function

De-

fault

AI2 - Alarmed Variable (Cont)

L418

5-4

AI2

0-5 V Input - Enter a value that matches the voltage range of
the Alarmed Variable signal. 1 = 0 - 5 V input range; 0 = 1 -
5 V input range.

0

L442

5-4

AI2

Square Root Signal - It is used if the Alarmed Variable input
is a squared signal value that must be linearized. 0 = input
is already linear; 1 = square root to restore linearization.

0

AI3 - Tracking Input (Output Tracking)

L119

5-9

CON0

Output Track Enable - This datapoint must be configured to a
1 so that Output Tracking can be enabled when DI0 is an
open contact.

0

C259

5-4

AI3

Engineering Span - Enter a value, that when added to the
Engineering Zero value, will produce an upper range value in
engineering units that represents the tracking input upper
range signal value.

0

C279

5-4

AI3

Engineering Zero - Enter a value that represents in
engineering units the tracking input lower range signal value.

0

B272

5-4

AI3

Digital Filter Index - This is a first order filter that can be
applied to the tracking input signal. See Table 5-4 for input
values.

3

L419

5-4

AI3

0-5 V Input - Enter a value that matches the signal voltage
range of the tracking input signal. 1 = 0 - 5 V input range;
0 = 1 - 5 V input range.

0

L443

5-4

AI3

Square Root Signal - It is used if the tracking input is a
squared signal value that must be linearized. 0 = input is
already linear; 1 = square root to restore linearization.

0

AO0 - Station Output

L472

5-5

AO0

0-20 mA Output - 0 = 4-20 mA signal; 1 = 0-20 mA signal.
Enter a value to match the output valve requirements.

0

L120

5-9

CON0

Manual Fallback Disable - 0 = always power up in manual;
1 = auto/manual selector unchanged at power up.

0

L122

5-9

CON0

Hard Manual Limit - 1 = apply output limits to the final output
of the Auto-Manual Generator. It affects both the manual
push buttons and the controller’s result. 0 = do not apply
limits.

1

C109

5-9

CON0

Output High Limit - Sets maximum Station Output signal
value in engineering units.

100

C110

5-9

CON0

Output Low Limit - Sets minimum Station Output signal value
in engineering units.

0

CON0 Control Related Datapoints

C115

5-9

CON0

Controller Span - Enter a value, that when added to the
Controller Lower Range value, will produce the control upper
range value in engineering units.

100

C116

5-9

CON0

Controller Lower Range - Enter a value that represents in
engineering units the control lower range value.

0

2 of 3

53MC5000 Process Control Station

10-6
