Table D-14. Database - L Type Datapoints
Data-
point
Name
Module
Atom
Default
Table
L266-
L281
DI2 through DI17 Discrete Input
Invert (Optional)
DI
IINV2-
IINV17
0
5-6
L282-
L287
DI18 through DI23 Discrete Input
Invert (Optional)
IINV18-
IINV23
0
L288
DO0 Discrete Output Invert
(Standard)
DO
OINV0
0
5-7
L289
DO1 Discrete Output Invert
(Standard)
OINV1
0
L290-
L305
DO2 through DO17 Discrete Output
Invert (Optional)
OINV2-
OINV17
0
L306-
L311
DO18 through DO23 Discrete
Output Invert (Optional)
OINV18-
OINV23
0
L312-
L319
Parameter Display Modules 0 thru 7
Modify Disable
Parameter
PMD0-
PMD7
0
5-11
L320-
L327
SDT0 Modify Display Disable 0 thru
7
Status
SDA0-
SDH0
0
5-10
L328-
L335
SDT1 Modify Display Disable 0 thru
7
SDA1-
SDH1
0
L336-
L343
SDT0 State 0 thru 7
SSA0-
SSH0
0
L344-
L351
SDT1 State 0 thru 7
SSA1-
SSH1
0
L352-
L359
SDT0 Mode 0 thru 7
SMA0-
SMH0
0
L360-
L367
SDT1 State 0 thru 7
SMA1-
SMH1
0
L368-
L375
SDT0 Alarm Enable 0 thru 7
SAA0-
SAH0
0
L376-
L383
SDT
1
Alarm Enable 0 thru 7
SAA1-
SAH1
0
L384-
L391
SDT0 Alarm Acknowledge 0 thru 7
SKA0-
SKH0
0
L392-
L399
SDT1 Alarm Acknowledge 0 thru 7
SKA1-
SKH1
0
L400-
L407
SDT0 Last State 0 thru 7
SLA0-
SLH0
0
L408-
L415
SDT1 Last State 0 through 7
SLA1-
SLH1
0
L416-
L419
AI0 through AI3 0-5 V Input
(Standard)
AI
NOBIAS0-
NOBIAS3
0
5-4
L420-
L424
AI4 through AI8 0-5 V Input
(Optional)
NOBIAS4-
NOBIAS8
0
L425-
L435
AI
n
0-5 V Input (Optional)
NOBIAS
n
0
5 of 6
Appendix D. Database
D-15
