Table D-8. Status Display Modules
Page * Name Atom SDT0 SDT1 Default
Name
Status Module Title TAG A054 A063 SDT0 , SDT1
Point 1 Name STA A055 A064 SDT0 = A, SDT1 = I
Point 2 Name STB A056 A065 SDT0 = B, SDT1 = J
Point 3 Name STC A057 A066 SDT0 = C, SDT1 = K
Point 4 Name STD A058 A067 SDT0 = D, SDT1 = L
Point 5 Name STE A059 A068 SDT0 = E, SDT1 = M
Point 6 Name STF A060 A069 SDT0 = F, SDT1 = N
Point 7 Name STG A061 A070 SDT0 = G, SDT1 = O
Point 8 Name STH A062 A071 SDT0 = H, SDT1 = P
Mode
SDT Mode 0 SMA L352 L360 0
SDT Mode 1 SMB L353 L361 0
SDT Mode 2 SMC L354 L362 0
SDT Mode 3 SMD L355 L363 0
SDT Mode 4 SME L356 L364 0
SDT Mode 5 SMF L357 L365 0
SDT Mode 6 SMG L358 L366 0
SDT Mode 7 SMH L359 L367 0
Alarm
SDT Alarm Enable 0 SAA L368 L376 0
SDT Alarm Enable 1 SAB L369 L377 0
SDT Alarm Enable 2 SAC L370 L378 0
SDT Alarm Enable 3 SAD L371 L379 0
SDT Alarm Enable 4 SAE L372 L380 0
SDT Alarm Enable 5 SAF L373 L381 0
SDT Alarm Enable 6 SAG L374 L382 0
SDT Alarm Enable 7 SAH L375 L383 0
Modify
Modify Disable 0 SDA L320 L328 0
Modify Disable 1 SDB L321 L329 0
Modify Disable 2 SDC L322 L330 0
Modify Disable 3 SDD L323 L331 0
Modify Disable 4 SDE L324 L332 0
Modify Disable 5 SDF L325 L333 0
Modify Disable 6 SDG L326 L334 0
Modify Disable 7 SDH L327 L335 0
SDT State 0 SSA L336 L344 0
SDT State 1 SSB L337 L345 0
SDT State 2 SSC L338 L346 0
SDT State 3 SSD L339 L347 0
SDT State 4 SSE L340 L348 0
