Table 11-3. CS20 Two Loop Controller Datapoints

Data-

point

Table

Module

Title and Function

De-

fault

AI3 - Remote Setpoint Loop 2 (Is affected by Setpoint Related Datapoints) (Cont)

C279

5-4

AI3

Engineering Zero - Enter a value that represents in
engineering units the Loop 2 Remote Setpoint lower range
signal value.

0

B272

5-4

AI3

Digital Filter Index - This is a first order filter that can be
applied to the Loop 2 Remote Setpoint signal. See Table 5-4
for input values.

3

L419

5-4

AI3

0-5 V Input - Enter a value that matches the signal voltage
range of the Loop 2 Remote Setpoint signal. 1 = 0 - 5 V
input range; 0 = 1 - 5 V input range.

0

L443

5-4

AI3

Square Root Signal - It is used if the Loop 2 Remote Setpoint
input is a squared signal value that must be linearized. 0 =
input is already linear; 1 = square root to restore linearization.

0

AO0 - Control Output Loop 1

L472

5-5

AO0

0-20 mA Output - 0 = 4-20 mA signal; 1 = 0-20 mA signal.
Enter a value to match the Loop 1 output valve requirements.

0

L120

5-9

CON0

Manual Fallback Disable - 0 = always power up in manual for
Loop 1; 1 = auto/manual selector unchanged at power up.

0

L122

5-9

CON0

Hard Manual Limit - 1 = apply output limits to the final output
of the Auto-Manual Generator for Loop 1. It affects both the
manual push buttons and the controller’s result. 0 = do not
apply limits.

1

C109

5-9

CON0

Output High Limit - Sets maximum Loop 1 Control Output
signal value for in engineering units.

100

C110

5-9

CON0

Output Low Limit - Sets minimum Loop 1 Control Output
signal value in engineering units.

0

C118

5-9

CON0

Output Slew Rate - It is a rate limit applied to the output
value. When configured to a non-zero value, the output from
the Auto-Selector for Loop 1 is only allowed to change by
this amount each scan time. A zero disables output slewing.
It does not affect manual operation.

0

CON0 Control Loop 1 Related Datapoints

C106

5-9

CON0

Proportional Band - Is the Loop 1 percent of error required to
move the output full scale for proportional action.

100

C107

5-9

CON0

Reset Time - Is the number of minutes per repeat of integral
action for Loop 1. It is mutually exclusive with Manual Reset.

0

C108

5-9

CON0

Rate Time - Represents the minutes Loop 1 proportional
action is advanced.

0

C111

5-9

CON0

Manual Reset - It determines Loop 1 output valve position
when the controller is in Auto and the error = 0. It is mutually
exclusive with Reset Time.

50

L106

5-9

CON0

Reverse Switch - 0 = Loop 1 Control Output

if Loop 1 PV

; 1 = Loop 1 Control Output

if Loop 1 PV

.

1

L114

5-9

CON0

Auto Enable - Controller output is from the Loop 1 PID
algorithm when set to 1 and A/M push button is in Auto.

1
