Table 5-10. Status Modules (SDT0 and SDT1)
Title Definition Atom SDT0 SDT1 Default
Point 0 Alarm Enable When this value is a 1, the Horn bit (L065) is set when
the corresponding SDT State changes from 0 to 1. The
displayed Point Name flashes as long as SDT State = 1
and SDT Alarm Acknowledge = 0.
0 - OFF
1 - ON
SAA L368 L376 0
Point 1 Alarm Enable SAB L369 L377 0
Point 2 Alarm Enable SAC L370 L378 0
Point 3 Alarm Enable SAD L371 L379 0
Point 4 Alarm Enable SAE L372 L380 0
Point 5 Alarm Enable SAF L373 L381 0
Point 6 Alarm Enable SAG L374 L382 0
Point 7 Alarm Enable SAH L375 L383 0
SDT Alarm Acknowledge 0 This parameter is set to 1 whenever State (SS) changes
from 0 to 1. It indicates an unacknowledged alarm and
must be cleared to 0 to acknowledge the alarm. SKA L384 L392 0
SDT Alarm Acknowledge 1 SKB L385 L393 0
SDT Alarm Acknowledge 2 SKC L386 L394 0
SDT Alarm Acknowledge 3 SKD L387 L395 0
SDT Alarm Acknowledge 4 SKE L388 L396 0
SDT Alarm Acknowledge 5 SKF L389 L397 0
SDT Alarm Acknowledge 6 SKG L390 L398 0
SDT Alarm Acknowledge 7 SKH L391 L399 0
SDT Last State Info 0 This parameter is used internally by the Controller. SLA L400 L408 0
SDT Last State Info 1 SLB L401 L409 0
SDT Last State Info 2 SLC L402 L410 0
SDT Last State Info 3 SLD L403 L411 0
SDT Last State Info 4 SLE L404 L412 0
SDT Last State Info 5 SLF L405 L413 0
SDT Last State Info 6 SLG L406 L414 0
SDT Last State Info 7 SLH L407 L415 0
3 of 4
