6.3 CS1 STANDARD DISPLAYS
Loading CS1 preconfigures the System Module display list for five displays. The five displays are
listed in Table 6-2 with appropriate reference sections, figure numbers, and configuration tables. A
configuration table is not listed for the Single Loop CON0 display, as that information is provided in
this section. To configure the Single Loop CON0 with Horizontal Trend, Parameter, and System
Status displays, reference the Section 4 and Section 5 information listed in the table.
Table 6-2. CS1 Standard Displays
Title
See
Section
Section 4
Figure
Section 5
Table
Single Loop CON0 4.3 and
4.3.1
4-3 sheet 1
Single Loop CON0 with Horizontal Trend 4.5 4-10 sheet 2 5-9
Parameter Module 0 - PID datapoints 4.6 4-11 5-11
Parameter Module 1 - Alarm Limits 4.6 4-11 5-11
System Status 4.2 4-2 5-15
6.4 CS1 DATAPOINT CONFIGURATION SELECTIONS
See Figure 6-2 and Table 6-3 to configure datapoints for CS1 - Single Loop (PID) Controller. Ta-
ble 6-3 also lists the Section 5 modules that can be referenced for more detailed definitions of the
datapoints when required.
A datapoint does not have to be configured if the default value
listed in Table 6-3 is appropriate for the process application. It should be noted that if all of the
CS1 setpoint and output functions are configured, controller operating precedence is as follows:
•
Setpoint priority - Setpoint Tracking, Remote Setpoint, and local setpoint setting with the
faceplate push buttons.
•
Output priority - Output Tracking, Auto (PID) Output, and local output setting with the face-
plate push buttons.
