Table D-13. System Module
Page *
Name
Atom
Datapoint
Default
Scan File Overrun Counter
OVR
B004
0
Background Overrun Counter
BOVR
B007
0
Initialization Message
A188
A189
NULL
NULL
Display List
B021 to B084
Expansion Board Slots 1 through 5
Population Identification Codes
SLT1
through
SLT5
B095
to
B099
0
Low Limit (High Selector) Two Loop
Override Controller
C088
C089
B202
0
0
Unchanged
Display Type
DSPT
B094
Process Control Station
PCS
B093
Unit Identifier
UID
A318
License Key
LKEY
A319
Counter Mode
CMODE
L075
0
HiRes Disable
HD
L076
0
* For 53MC5000B Firmware only
53MC5000 Process Control Station
D-10
