Table D-7. Controller (CON) Modules
Page * Name Atom CON0 CON1 CON2 CON3 Default
General
Control Tagname TAG A000 A002 A004 A006 CON-0/1/2/3
Controller Span IR C115 C151 C187 C223 100
Controller Lower Range IRL C116 C152 C188 C224 0
Trend Rate CTR B336 B341 B346 B351
B336 = 2,
B341, B346,
& B351 = 0.
Trend Mode CTM B337 B342 B347 B352 0
Control Display Mode CDM B339 B344 B349 B354 0
Engineering Units EU A001 A003 A005 A007 PERCENT
Setpoint
Setpoint Mode SPM B338 B343 B348 B353 0
Setpoint SP C101 C137 C173 C209 0
Remote Setpoint RSP C120 C156 C192 C228 0
Setpoint High Limit SH C125 C161 C197 C233 100
Setpoint Low Limit SL C126 C162 C198 C234 0
Setpoint Track Value STV C128 C164 C200 C236 0
Remote SP Bias B1 C112 C148 C184 C220 0
Remote SP Ratio K1 C113 C149 C185 C221 1
Setpoint Slew Rate SSR C117 C153 C189 C225 0
Alarm
Alarm Limit 1 PL1 C103 C139 C175 C211 100
Alarm Limit 2 PL2 C104 C140 C176 C212 0
Alarm Dead Band ADB C105 C141 C177 C213 2
Control Alarm Acknowledge AK L125 L149 L173 L197 0
Control Alarm Mode AIX B335 B340 B345 B350 1
Tune
Proportional Band PB C106 C142 C178 C214 100
Reset Time TR C107 C143 C179 C215 0
Rate Time TD C108 C144 C180 C216 0
Manual Reset MR C111 C147 C183 C219 50
Control Zone CZ C114 C150 C186 C222 0
Reverse Switch RSW L106 L130 L154 L178 1
Feed Forward FF C122 C158 C194 C230 0
Output
Output OUT C102 C138 C174 C210 0
Output High Limit OH C109 C145 C181 C217 100
Output Low Limit OL C110 C146 C182 C218 0
Output Slew Rate OSR C118 C154 C190 C226 0
Output Track Value OTV C129 C165 C201 C237 0
Reverse Valve RSV L109 L133 L157 L181 0
Manual Fallback Disable MFD L120 L144 L168 L192 0
Hard Manual Limit HML L122 L146 L170 L194 1
1 of 2
