Micromod Micro-DCI: 53MC5000 Multi-Loop Process Controller Instruction Manual - Manual (Page 147)

Input
Mod-
ules
General Modules Output
Modules
AI0 CON0 SDT0 PAR0 TREND0 TOT0 AO0
AI1 CON1 SDT1 PAR1 TREND1 TOT1 AO1
AI2 CON2 PAR2 TREND2 TOT2 AO2
AI3 CON3 PAR3 TREND3 TOT3 AO3
AI4 PAR4 TREND4 TOT4
AI5 PAR5 TREND5 TOT5
AI6 PAR6 TREND6 TOT6
AI7 PAR7 TREND7 TOT7
AI8
Control Algorithms
DI0 DO0
DI1 DO1
DI2 DO2
DI3 DO3
DI4 DO4
DI5 FIX 1 (B000 = 1) Flexible Control Strategy DO5
DI6 or FIX 99 (B000 = 99) F-CIM DO6
DI7 or FIXs 2-89 & 101-255 (B000 = FIX Number) DO7
DI8 F-TRAN DO8
DI9 DO9
DI10 DO10
DI11 DO11
DI12 DO12
DI13 DO13
DI14 DO14
DI15 DO15
DI16 DO16
DI17 DO17
External Communications
Mini DIN Configuration Port
Standard Communications (Datalink) (RS-485) COMM
MicroLink (RS-485) EXT0-23, COMM
= Does not require an Expansion Board with Option Cards and
associated ITBs (is provided with all controllers).
Notes: AI0-8 = Analog Input Modules, DI0-17 = Contact Closure
Input Modules, CON0-3 = Controller Modules, SDT0&1 = Status
Display Modules, PAR0-7 = Parameter Display Modules,
TREND0-7 = Trend Modules, TOT0-7 = Totalizer Modules
SYS = System Module, AO0-3 = Analog Output Modules,
DO0-17 = Contact Closure Output Modules,
COMM = Communication Module, EXT0-23 = External I/O Module
Figure 5-1. Database Modules
Multi I/O
Analog Op-
tion
Multi I/O
Analog
Option
Single
Channel
Analog
Input
Option
6DI/4DO
Option
6DI/4DO
Option
16DI/DO
Option
(16 Mod-
ules
Maxi-
mum on
ITB)
16DI/DO
Option (16
Modules
Maximum
on
ITB)
Micro-
Link
Option
53MC5000 Process Control Station
