Table 1-9. SCADA Board Specifications
Item
Specification(s)
Safety classification
FM Approved: Nonincendive for Class 1, Div. 2, Group A,
B, C, & D hazardous locations.
Dimensions
10 in. (254 mm) long, 2.740 in. (70 mm) wide.
Power requirements
+12 V dc or +24 V dc @ 100 ma.
Modem baud rate
600, 1200, 2400, 4800, 9600, 19,200, 28,800, and 38,400.
Data protocol
Eight data bits, one stop bit.
Modem parity
Even or none.
Modem delay
10, 20, 30, 40, 50, 100, 200, and 250 milliseconds.
Datalink baud rate
9,600 or 28,800.
LEDs on SCADA board:
CTS - Clear to Send
RTS - Request to Send
M_R - Modem Receive
M_T - Modem Transmit
D_R - Datalink Receive
D_T - Datalink Transmit
The modem is ready to receive data from the SCADA board.
The SCADA board wishes to transmit to the modem.
The data line from the modem to the SCADA board.
The data line from the SCADA board to the modem.
The data line from the controllers to the SCADA board.
The data line from the SCADA board to the controllers.
1.5 RELATED DOCUMENTATION
Other documents related to the 53MC5000 Process Control Station are summarized in the list that
follows. It should be noted that the list contains the latest editions of the referenced documents as
of the release date for this book; therefore, documents in the list may be at higher revision levels
than the ones shown or may be superseded by new books.
•
Publication Number 24568, Instruction Bulletin 53MC5000 Flexible Control Strate-
gies.
This book provides information to configure soft-wire lists for the Flexible Control Strategy
(FCS) modules. An overview figure shows all of the FCS modules and each module type
is presented in the book with an illustration and functional description. The book also has
soft-wire lists and function block diagrams of the ten resident control strategies (CS1-5,
20-22, 40, and 41) to aid in modifying an existing control strategy.
•
Publication Number 24975, Customization Guide 53MC5000, MICRO-DCI
Modular
Controller.
This is a guide used to create F-TRAN programs and F-CIM sequence configurations for
the 53MC5000 Process Control Station.
•
Publication Number 24365, Instruction Bulletin 53SU5000, Revision 1, Design Level
B Software Release 4.
This book provides installation and operating information for the SUPERVISOR-PC soft-
ware that runs under MS-DOS on a personal computer, for the MicroMod operator
keyboard, and for the expansion slot SUPERVISOR-PC card(s). It also provides descrip-
tive information for the following product package capabilities: personal computer commu-
nication from a COM port or the SUPERVISOR card(s) to the standard datalink network;
personal computer communication from the SUPERVISOR card(s) to a MicroLink network;
how a personal computer can be used to create hierarchical color displays, graphical
