Table D-16. Database - C Type Datapoints
Data-
point
Name Module Atom Default Table
C311 Trend 4 Span
Trend
TRS4 0
5-12
C312 Trend 5 Zero TRZ5 0
C313 Trend 5 Span TRS5 0
C314 Trend 6 Zero TRZ6 0
C315 Trend 6 Span TRS6 0
C316 Trend 7 Zero TRZ7 0
C317 Trend 7 Span TRS7 0
C318 Totalizer Module 0 - Scale Factor
Totalizer
TMF0 0
5-13
C319 Totalizer Module 0 - Drop Out TMD0 0
C320 Totalizer Module 1 - Scale Factor TMF1 0
C321 Totalizer Module 1 - Drop Out TMD1 0
C322 Totalizer Module 2 - Scale Factor TMF2 0
C323 Totalizer Module 2 - Drop Out TMD2 0
C324 Totalizer Module 3 - Scale Factor TMF3 0
C325 Totalizer Module 3 - Drop Out TMD3 0
C326 Totalizer Module 4 - Scale Factor TMF4 0
C327 Totalizer Module 4 - Drop Out TMD4 0
C328 Totalizer Module 5 - Scale Factor TMF5 0
C329 Totalizer Module 5 - Drop Out TMD5 0
C330 Totalizer Module 6 - Scale Factor TMF6 0
C331 Totalizer Module 6 - Drop Out TMD6 0
C332 Totalizer Module 7 - Scale Factor TMF7 0
C333 Totalizer Module 7 - Drop Out TMD7 0
C334-
C343
Reserved Temporaries
BCTEMP
7 - 16
0
C344-
C353
Reserved Temporaries
FCTEMP
7 - 16
0
C354-
C377
Extended Math 0-1 (K1-K12) 0
C378 Initial PV Response Limit
EASY-
TUNE
DPPV 2
17-2
C379 Initial PV Response Time 0 0
C380 Maximum PV Deviation Allowed DPV 0
C381 Output step change Value 0 DOUT 0
C382 Tp - Time Constant Modifier 0.1
C383 Kp - Process Gain Modifier 0.1
C384 Wp - Dead Time Modifier 0.1
C385 Lowest % PB 2
C386 Highest % PB 500
C387 Lowest TR Minutes TLIM 0
C388 Highest TR Minutes 30
C389 Lowest TD Minutes 0
6 of 7
53MC5000 Process Control Station
D-28
