Table 5-13. Totalizer Modules

Parameter

Definition

Symbol

0

1

2

3

4

5

6

7

Default

Actual
Total

This parameter indicates the integer value of the total
accumulation.

TO

(0-7)

H032 H033 H034 H035 H036 H037 H038 H039

0

Output
Pulse

This value is pulsed to a

1 for one scan each time the

actual total reaches the rollover value.

TMP
(0-7)

L224 L225 L226 L227 L228 L229 L230 L231

0

Display

This is the index number for the display that provides
access through the totalizer module.

23

24

25

26

27

28

29

30
