Table D-14. Database - L Type Datapoints
Data-
point
Name Module Atom Default Table
L138 Auto Enable
Controller 1
AE1 1
5-9
L139 Remote Setpoint Enable RE1 0
L140 Setpoint Track Switch SWSPT1 0
L141 Output Track Switch SWOVT1 0
L142 Setpoint Track Enable STE1 0
L143 Output Track Enable OTE1 0
L144 Manual Fallback Disable MFD1 0
L145 Reserved 0
L146 Hard Manual Limit HML1 1
5-9
L147 Control Track Command CTC1 0
L148 Reserved 0
L149 Alarm Acknowledge AK1 0
5-9
L150 Alarm AA Past State LA1 0
L151 Alarm AB Past State LB1 0
L152 SP Track Status
Controller 2
SPTS2 0
L153 Output Track Status OVTS2 0
L154 Reverse Switch RSW2 1
L155 Auto Status AUT2 0
L156 Remote Status RMT2 0
L157 Reverse Valve RSV2 0
L158 Alarm A Active PA12 0
L159 Alarm B Active PA22 0
L160 Auto Switch SWA2 0
L161 Remote Switch SWR2 0
L162 Auto Enable AE2 1
L163 Remote Setpoint Enable RE2 0
L164 Setpoint Track Switch SWSPT2 0
L165 Output Track Switch SWOVT2 0
L166 Setpoint Track Enable STE2 0
L167 Output Track Enable OTE2 0
L168 Manual Fallback Disable MFD2 0
L169 Reserved 0
L170 Hard Manual Limit HML2 1
5-9
L171 Control Track Command CTC2 0
L172 Reserved 0
L173 Alarm Acknowledge AK2 0
5-9
L174 Alarm AA Past State LA2 0
L175 Alarm AB Past State LB2 0
L176 SP Track Status
Controller 3
SPTS3 0
L177 Output Track Status OVTS3 0
L178 Reverse Switch RSW3 1
L179 Auto Status AUT3 0
3 of 6
Appendix D. Database
D-13
