Table D-5. Discrete Output Modules
Name Atom DO
0
DO
1
DO
2
DO
3
DO
4
DO
5
DO
6
DO
7
DO
8
Default
Discrete Output DO L024 L025 L026 L027 L028 L029 L030 L031 L032 0
Discrete Output
Invert
OINV L288 L289 L290 L291 L292 L293 L294 L295 L296 0
Tag Name TAG A280 A281 A282 A283 A284 A285 A286 A287 A288
Name Atom DO
9
DO
10
DO
11
DO
12
DO
13
DO
14
DO
15
DO
16
DO
17
Default
Discrete Output DO L033 L034 L035 L036 L037 L038 L039 L040 L041 0
Discrete Output
Invert
OINV L297 L298 L299 L300 L301 L302 L303 L304 L305 0
Tag Name TAG A289 A290 A291 A292 A293 A294 A295 A296 A297
Table D-6. External I/O Module
Name Atom 0 1 2 3 4 5 6 7
Remote Point PSRC A128 A130 A132 A134 A136 A138 A140 A142
Local Point PDST F352 F353 F354 F355 F356 F357 F358 F359
Scan PSCAN B400 B401 B402 B403 B404 B405 B406 B407
Mode PMODE B424 B425 B426 B427 B428 B429 B430 B431
Status PSTAT L200 L201 L202 L203 L204 L205 L206 L207
Name Atom 8 9 10 11 12 13 14 15
Remote Point PSRC A144 A146 A148 A150 A152 A154 A156 A158
Local Point PDST F360 F361 F362 F363 F364 F365 F366 F367
Scan PSCAN B408 B409 B410 B411 B412 B413 B414 B415
Mode PMODE B432 B433 B434 B435 B436 B437 B438 B439
Status PSTAT L208 L209 L210 L211 L212 L213 L214 L215
Name Atom 16 17 18 19 20 21 22 23
Remote Point PSRC A160 A162 A164 A166 A168 A170 A172 A174
Local Point PDST F368 F369 F370 F371 F372 F373 F374 F375
Scan PSCAN B416 B417 B418 B419 B420 B421 B422 B423
Mode PMODE B440 B441 B442 B443 B444 B445 B446 B447
Status PSTAT L216 L217 L218 L219 L220 L221 L222 L223
