Table D-15. Database - B Type Datapoints
Data-
point
Name Module Atom Default Table
B376 Rate
Trend 7
TRR7 0
5-12
B377 Mode TRM7 0
B378 Height TRH7 47
B379 Database Identifier
B380
Product Identifier (0 = 53MC5000,
1 = 53SL5100A, 2 = 53IT5100A,
3 = 53ML5100A)
0
B381 For internal controller use.
B382 Software Level
B383 System ROM Checksum
B384 PIC Code PIC
B385
EASY-TUNE Control Module
Selector
EASY-
TUNE
Parameters
LPS 0
17-2
B386 EASY-TUNE PID Control Mode CM 0
B387 EASY-TUNE Status
Successful
Unsuccessful
0
17-3
17-4
B388-
B389
EASY-TUNE internal use (updated
every scan)
0
B400 Task 0 Scan
External I/O
SCAN0 0
5-8
B401 Task 1 Scan SCAN1 0
B402 Task 2 Scan SCAN2 0
B403 Task 3 Scan SCAN3 0
B404 Task 4 Scan SCAN4 0
B405 Task 5 Scan SCAN5 0
B406 Task 6 Scan SCAN6 0
B407 Task 7 Scan SCAN7 0
B408 Task 8 Scan SCAN8 0
B409 Task 9 Scan SCAN9 0
B410 Task 10 Scan SCAN10 0
B411 Task 11 Scan SCAN11 0
B412 Task 12 Scan SCAN12 0
B413 Task 13 Scan SCAN13 0
B414 Task 14 Scan SCAN14 0
B415 Task 15 Scan SCAN15 0
B416 Task 16 Scan SCAN16 0
B417 Task 17 Scan SCAN17 0
B418 Task 18 Scan SCAN18 0
B419 Task 19 Scan SCAN19 0
B420 Task 20 Scan SCAN20 0
B421 Task 21 Scan SCAN21 0
B422 Task 22 Scan SCAN22 0
