Table 5-9. Controller Modules (CON0-3)
Title Definition Atom CON0 CON1 CON2 CON3 Default
Deviation The output of the deviation module and it
equals Process Variable (PV) minus Control
Setpoint (TSP) modified by Control Zone (CZ). DV
(0-3)
C121 C157 C193 C229 0
Feed Forward This parameter is a bias value added to the
output as necessitated by the process for
proper control. FF
(0-3)
C122 C158 C194 C230 0
Control Output The output of the PID function. CO
(0-3)
C123 C159 C195 C231 0
Partial Output Term Used internally by the controller PN
(0-3)
C124 C160 C196 C232 0
Setpoint High Limit These two parameters are configured to
indicate the maximum and minimum controller
setpoint values allowed. They are applied to
the final output of the setpoint generator and
therefore affect the remote and track setpoint
results.See Remote Setpoint Enable (RE) and
Setpoint Tracking Enable (STE). SH (0-3) C125 C161 C197 C233 100
Setpoint Low Limit SL (0-3) C126 C162 C198 C234 0
Reset Feedback A term used by the PID function to calculate
the output. RF
(0-3)
C127 C163 C199 C235 0
Setpoint Track Value The output of the Setpoint Generator when
Setpoint Track Status (SPTS) equals
1.
STV
(0-3)
C128 C164 C200 C236 0
Output Track Value The output of the Auto/Manual Selector when
Output Track Status (OVTS) equals
1.
OTV
(0-3)
C129 C165 C201 C237 0
Reset Generator Used internally by the controller RN
(0-3)
H020 H023 H026 H029 0
Rate Generator Used internally by the controller DN
(0-3)
H021 H024 H027 H030 0
Control Tagname This is an assignable 10 character name that
appears on the displays. TAG A000 A002 A004 A006 CON-
0/1/2/3
Engineering Units This is an assignable 10 character units of
measure associated with the Process Variable
(PV). EU A001 A003 A005 A007 PERCENT
