10.3 CS5 STANDARD DISPLAYS
Loading CS5 preconfigures the System Module display list for five displays. The five displays are
listed in Table 10-2 with appropriate reference sections, figure numbers, and configuration tables.
A configuration table is not listed for the Ratio Auto/Manual Point Display 3, as that information is
provided in this section. To configure the Single Loop CON0 with Horizontal Trend, Parameter,
and System Status displays, reference the Section 4 and Section 5 information listed in the table.
Table 10-2. CS5 Standard Displays
Title
See
Section
Section 4
Figure
Section 5
Table
Ratio Auto/Manual Point Display 3 (CDM = 5) 4.3 and
4.3.6
4-8
Single Loop with Horizontal Trend - As shown below, the
trend module for the Ratio Automatic/Manual Station is
slightly different than the one illustrated in Figure 4-10. 4.5 4-10 sheet 2
and figure
below
5-9
Parameter Module 0 - PID datapoints are not applicable
for this control strategy; therefore, this parameter module
can be ignored or reconfigured to display three other
datapoints that are frequently referenced. 4.6 4-11 5-11
Parameter Module 1- Alarm Limits 4.6 4-11 5-11
System Status 4.2 4-2 5-15
10.4 CS5 DATAPOINT CONFIGURATION SELECTIONS
See Figure 10-2 and Table 10-3 to configure datapoints for CS5 - Ratio Automatic/Manual Station.
Table 10-3 also lists the Section 5 modules that can be referenced for more detailed definitions of
the datapoints when required.
A datapoint does not have to be configured if the default value
listed in Table 10-3 is appropriate for the process application. Loading CS5 initializes the Engi-
neering Span (C257) to 100 for AI1 (Remote Ratio Input), it sets the CON0 Display Mode (B339) to
5, and sets the CON0 Setpoint Mode (B338) to 1.
AI2 - ALARMED VARIABLE
AI0 - AUTO INPUT
AO0 - STATION OUTPUT
80 S 0.0
PERCENT
AR
IN 50.56
OV 62.33
(THERE IS NO SETPOINT
VALUE IN THE BOTTOM
LEGEND)
Section 10. CS5 - Ratio Automatic/Manual Station
10-3
