Based on the selection made from this menu, one of the following operations can occur:
•
F2- DATABASE: This operation copies the entire data-
base, all B, L, C, H, and A, datapoint values, in the
controller to the memory module. This transfer takes
approximately 12 seconds.
•
F3- PROGRAM: This selection copies the F-TRAN pro-
grams and F-CIM module sequences from the control-
l er t o t he me mo ry mo du l e. Thi s t ransfer takes
approximately 20 seconds.
When the transfer begins a message is displayed indicating the transfer has started.
Another message appears when the transfer is completed. If the transfer fails, an error
message is displayed instead of the transfer completed message. If an error does occur,
resolve the cause and re-initiate the transfer. A transfer error should not be ignored, as
a partial transfer may cause the HHC memory module to contain corrupted data. The
HHC returns to the command entry mode if the transfer is successful or if it is halted with
an error message.
3.13.1.6 SAMPLE HAND HELD CONFIGURER COMMANDS
The following table provides a sample of typical Hand Held Configurer Display (
D ), Put (P ), and
Memory Transfer (
T ) commands.
Key Entries
Displayed Data
Result
D B101
D B101 XXX
Displays contents of B101.
D N
D B102 XXX
Displays contents of Next (N)
datapoint, B102.
D
D B102 XXX
B102 contents still displayed. It
updates the display value of the
current datapoint.
P C256
P C256 XXX 200
Alters contents of C256 to 200
P
P C256 XXX 150
Alters contents of C256 to 150.
It alters the value of the current
datapoint.
P N 200
P C257 XXX 200
Alters contents of C257 to 200.
It alters the value of the Next (N)
datapoint.
T
MEMORY TRANSFER
F1 - TO CONTROLLER
F2 - FROM CONTROLLER
✦
✦
✦
TRANSFER FINISHED
Displays memory transfer query
t o e i t h e r s e n d c a l i b r a t i o n
c o n s t a n t s , d a t a b a s e , o r
programs to the instrument; or
receive database or programs
from the instrument for storage
into the memory module.
Note:
XXX = Displayed characters from the addressed datapoint.
