Table 1-1. 53MC5000 Process Control Station Specifications

Item

Specification(s)

Enclosure classification/environment
(cont)

Rated for installation in a "Pollution Degree 2" location per
U.L. 508-1989/"Controlled Environment" per CSA C22.2 No.
142-M1987. An indoor, temperature controlled location
(control room or shop floor) where normally, only non-
conductive pollution occurs; however, temporary
conductivity caused by condensation may be expected.

Location in environments more severe than the above
requires supplementary protection.

Shock vibration

0.5 g, ISA, G3.

Vibration

SAMA PMC 31.1-1978; point to point constant displacement
0.05" (1.27mm), 5 to 14 Hz: 0.5 g, 14 to 200 Hz.

Drop and topple

SAMA PMC 31.1-1978; Tilt 30 degrees from horizontal and
fall freely to a hard surface, all sides, front and back.

Safety classification

A) General Purpose: Complies with ANSI/ISA S82.01-1988,
Safety Standard for Electrical and Electronic Test,
Measuring, Controlling and Related Equipment; General
Requirements and S82.03-1988 Safety Standard for
Electrical and Electronic Test, Measuring, Controlling and
Related Equipment; Electrical and Electronic Process
Measurement and Control Equipment.
B) FM Approved: Nonincendive for Class I, Div 2, Groups
A, B, C & D hazardous locations.

Physical characteristics:
Construction materials:
Case
Circuit boards
Bezel

Instruments dimensions

Steel, Light Gray enamel.
Glass epoxy.
ULTEM 1000

®

(Polyetherimide Resin) Flammability-UL94

5V.

2.844 W x 5.656 H x 12.906 L (inches)
73 W x 144 H x 329 L (mm)

Flush panel mounting

0.125 inch to 1 inch thickness (3.2mm to 25.4mm).

Electrical connections

Rear of case screw type terminal block.

Weight (approximate)

5 pounds (2.3 kg).

PID control ranges:
Proportional band

Integral

Derivative

2% to 1000% and

off.

0.02 to 200 min./repeat, or Manual Reset from 0 to 100%.

0.01 to 8 minutes advanced and

off.

Front panel:
Display - High Resolution
- Low Resolution

Push buttons

192 x 96 dot matrix addressable.
96 x 48 dot matrix addressable.

10 membrane type switches.

3 of 4

53MC5000 Process Control Station

1-12
