Table 1-7. Multichannel Analog Option Specifications

Item

Specification(s)

Saftey classification

FM Approved: Nonincendive for Class 1, Div. 2, Group A,
B, C, & D hazardous locations.

Non-Isolated Analog Inputs (AI4 - AI7)

Quantity

4

Connection type

Track mounted ITB.

Transmitter power

Supplied by user to ITB.

Current to voltage resistors

Provided on ITB (250 ohm

±

0.1% tolerance).

Current signals:
Signal Range
Measurement accuracy
Voltage measurement accuracy

0 - 21.84 mA

±

0.2% of Full Scale

±

0.1% of Full Scale

Frequency signals:
Signal range
Input impedance
Measurement accuracy
Signal amplitude
Pulse width

9 - 25,000 Hz
47 k ohms in series with a 0.22 MFD capacitor.

±

0.2% of rate

4 - 25 V p-p
20 microseconds minimum

NOTE

The minimum frequency of 9 Hz and minimum voltage of 4 V p-p

assumes the input waveform has a 50% duty cycle. The 53MC5000

Process Control Station frequency inputs are capacitively coupled into

a level sensitive Schmidt Trigger; therefore, the dc bias level of the

signal is not important. If, however, the duty cycle is not adhered to

larger signal amplitudes are required and low frequency accuracy will

degrade.

The following formula is provided to calculate required signal amplitudes for duty cycles other
than 50%:

Required Amplitude

=

|

2

5

(

%

Duty Cycle

50

)

|

+

4

If the duty cycle is 50%, then the required amplitude is 4 V p-p.
If the duty cycle is 10%, then the required amplitude is 20 V p-p.
If the duty cycle is 90%, then the required amplitude is 20 V p-p.

Pulse signals:
Signal range
Input impedance
Signal amplitude
Pulse width
Rollover pulse count

0 - 25,000 Hz
47 k ohms in series with a 0.22 MFD capacitor.
4 - 25 V p-p
20 microseconds minimum
10,000,000

Isolated Analog Input (AI8)

This option requires one of the 5B series isolation modules described in Table 1-8.

Quantity

1 (Analog Input 8 - AI8).

Analog-to-digital specifications:
Accuracy
Resolution

±

0.1% Full Scale

12 bits

1 of 2
