Table D-15. Database - B Type Datapoints
Data-
point
Name Module Atom Default Table
B334 Last Control Strategy Loaded LCS 0
B335 Alarm Mode
Controller 0
AIX0 1
5-9
B336 Trend Rate CTR0 2
B337 Trend Mode CTM0 0
B338 Setpoint Mode SPM0 0
B339 Display Mode CDM0 0
B340 Alarm Mode
Controller 1
AIX1 1
B341 Trend Rate CTR1 0
B342 Trend Mode CTM1 0
B343 Setpoint Mode SPM1 0
B344 Display Mode CDM1 0
B345 Alarm Mode
Controller 2
AIX2 1
B346 Trend Rate CTR2 0
B347 Trend Mode CTM2 0
B348 Setpoint Mode SPM2 0
B349 Display Mode CDM2 0
B350 Alarm Mode
Controller 3
AIX3 1
B351 Trend Rate CTR3 0
B352 Trend Mode CTM3 0
B353 Setpoint Mode SPM3 0
B354 Display Mode CDM3 0
B355 Rate
Trend 0
TRR0 0
5-12
B356 Mode TRM0 0
B357 Height TRH0 47
B358 Rate
Trend 1
TRR1 0
B359 Mode TRM1 0
B360 Height TRH1 47
B361 Rate
Trend 2
TRR2 0
B362 Mode TRM2 0
B363 Height TRH2 47
B364 Rate
Trend 3
TRR3 0
B365 Mode TRM3 0
B366 Height TRH3 47
B367 Rate
Trend 4
TRR4 0
B368 Mode TRM4 0
B369 Height TRH4 47
B370 Rate
Trend 5
TRR5 0
B371 Mode TRM5 0
B372 Height TRH5 47
B373 Rate
Trend 6
TRR6 0
B374 Mode TRM6 0
B375 Height TRH6 47
3 of 6
Appendix D. Database
D-19
