Table 15-3. CS41 Four Loop Controller Datapoints
Data-
point Table Module Title and Function
De-
fault
CCI4 - Force Fallback Loop 1 (Cont)
L119 5-6 CON0 Output Track Enable - Enter a 1 into this datapoint to force
the Control Output Loop 1 value to match the value in
datapoint C129 whenever CCI4 has an open condition and
Remote is selected with the R/L push button. 0
L118 5-6 CON0 Setpoint Track Enable - Enter a 1 into this datapoint to force
the Loop 1 setpoint value to match the value in datapoint
C128 whenever CCI4 has an open condition and Remote is
selected with the R/L push button. 0
CCI5 - Force Fallback Loop 2
L269 5-6 CCI5 Contact Input Invert - Normally, Force Fallback Loop 1 is
permitted if CCI5 is open. Set to 1 to reverse the CCI5
condition required to permit Force Fallback Loop 2 (CCI5
closed = Force Fallback Loop 2). 0
C165 5-6 CON1 Output Track Value - The Control Output Loop 2 can be
forced to match the value in this datapoint if CCI5 - Force
Fallback Loop 2 is open, L143 - Output Track Enable is
configured to a 1, and Remote is selected with the R/L
faceplate push button. 0
C164 5-6 CON1 Setpoint Track Value - The Loop 2 setpoint can be forced to
match the value in this datapoint if CCI5 - Force Fallback
Loop 2 is open, L142 - Setpoint Track Enable is configured
to a 1, and Remote is selected with the R/L faceplate push
button. 0
L143 5-6 CON1 Output Track Enable - Enter a 1 into this datapoint to force
the Control Output Loop 2 value to match the value in
datapoint C165 whenever CCI5 has an open condition and
Remote is selected with the R/L push button. 0
L142 5-6 CON1 Setpoint Track Enable - Enter a 1 into this datapoint to force
the Loop 2 setpoint value to match the value in datapoint
C164 whenever CCI5 has an open condition and Remote is
selected with the R/L push button. 0
CCI6 - Force Fallback Loop 3
L270 5-6 CCI6 Contact Input Invert - Normally, Force Fallback Loop 3 is
permitted if CCI6 is open. Set to 1 to reverse the CCI6
condition required to permit Force Fallback Loop 3 (CCI6
closed = Force Fallback Loop 3). 0
C201 5-6 CON2 Output Track Value - The Control Output Loop 3 can be
forced to match the value in this datapoint if CCI6 - Force
Fallback Loop 3 is open, L167 - Output Track Enable is
configured to a 1, and Remote is selected with the R/L
faceplate push button. 0
C200 5-6 CON2 Setpoint Track Value - The Loop 3 setpoint can be forced to
match the value in this datapoint if CCI6 - Force Fallback
Loop 3 is open, L166 - Setpoint Track Enable is configured
to a 1, and Remote is selected with the R/L faceplate push
button. 0
10 of 13
53MC5000 Process Control Station
15-18
