8.3 CS3 STANDARD DISPLAYS

Loading CS3 preconfigures the System Module display list for five displays. The five displays are
listed in Table 8-2 with appropriate reference sections, figure numbers, and configuration tables. A
configuration table is not listed for the Ratio Controller Single Loop CON0 display, as that informa-
tion is provided in this section. To configure the Single Loop CON0 (Ratio) with Horizontal Trend,
Parameter, and System Status displays, reference the Section 4 and Section 5 information listed in
the table.

Table 8-2. CS3 Standard Displays

Title

See

Section

Section 4

Figure

Section 5

Table

Ratio Controller (Point Display 3, CDM = 3)

4.3 and

4.3.4

4-6

Single Loop with Horizontal Trend (Ratio)

4.5

4-10 sheet 2

5-9

Parameter Module 0 - PID datapoints

4.6

4-11

5-11

Parameter Module 1- Alarm Limits

4.6

4-11

5-11

System Status

4.2

4-2

5-15

8.4 CS3 DATAPOINT CONFIGURATION SELECTIONS

See Figure 8-2 and Table 8-3 to configure datapoints for CS3 - Ratio (PID) Controller.
Table 8-3 also lists the Section 5 modules that can be referenced for more detailed definitions of
the datapoints when required.

A datapoint does not have to be configured if the default value

listed in Table 8-3 is appropriate for the process application. Loading CS3 initializes the Engi-
neering Span (C257) to 100 for AI1 (Wild Variable). Also, the CON0 Display Mode (B339) is set to
3; the CON0 Setpoint Mode (B338) is set to 1; and datapoint C081 (Math B - K3) is set to 1.0.

Section 8. CS3 - Ratio (PID) Controller

8-3
