Table 5-8. External Module (Tasks 0-23)
Title Definition Atom 8 9 10 11 12 13 14 15
Remote
Point
Same as above.
RPT
(8-15)
A144 A146 A148 A150 A152 A154 A156 A158
Local
Point LPT
(8-15)
F360 F361 F362 F363 F364 F365 F366 F367
Scan SCAN
(8-15)
B408 B409 B410 B411 B412 B413 B414 B415
Mode MODE
(8-15)
B432 B433 B434 B435 B436 B437 B438 B439
Status STAT
(8-15)
L208 L209 L210 L211 L212 L213 L214 L215
Title Definition Atom 16 17 18 19 20 21 22 23
Remote
Point
Same as above.
RPT
(16-23)
A160 A162 A164 A166 A168 A170 A172 A174
Local
Point LPT
(16-23)
F368 F369 F370 F371 F372 F373 F374 F375
Scan SCAN
(16-23)
B416 B417 B418 B419 B420 B421 B422 B423
Mode MODE
(16-23)
B440 B441 B442 B443 B444 B445 B446 B447
Status STAT
(16-23)
L216 L217 L218 L219 L220 L221 L222 L223
2 of 2
