Table 15-3. CS41 Four Loop Controller Datapoints

Data-

point

Table

Module

Title and Function

De-

fault

AO0 - Control Output Loop 1 (Cont)

C118

5-9

CON0

Output Slew Rate - It is a rate limit applied to the output
value. When configured to a non-zero value, the output from
the Loop 1 Auto-Selector is only allowed to change by this
amount each scan time. A zero disables output slewing. It
does not affect manual operation.

0

CON0 Control Loop 1 Related Datapoints

C106

5-9

CON0

Proportional Band - Is the Loop 1 percent of error required to
move the output full scale for proportional action.

100

C107

5-9

CON0

Reset Time - Is the number of minutes per repeat of integral
action for Loop 1. It is mutually exclusive with Manual Reset.

0

C108

5-9

CON0

Rate Time - Represents the minutes Loop 1 proportional
action is advanced.

0

C111

5-9

CON0

Manual Reset - It determines Loop 1 output valve position
when the controller is in Auto and the error = 0. It is mutually
exclusive with Reset Time.

50

L106

5-9

CON0

Reverse Switch - 0 = Loop 1 Control Output

if Loop 1 PV

; 1 = Loop 1 Control Output

if Loop 1 PV

.

1

L114

5-9

CON0

Auto Enable - Controller output is from the Loop 1 PID
algorithm when set to 1 and A/M push button is in Auto.

1

C115

5-9

CON0

Controller Span - Enter a value, that when added to the Loop
1 Controller Lower Range value, will produce the Loop 1
control upper range value in engineering units.

100

C116

5-9

CON0

Controller Lower Range - Enter a value that represents in
engineering units the Loop 1 control lower range value.

0

AO1 - Control Output Loop 2

L473

5-5

AO1

0-20 mA Output - 0 = 4-20 mA signal; 1 = 0-20 mA signal.
Enter a value to match the Loop 2 output valve requirements.

0

L144

5-9

CON1

Manual Fallback Disable - 0 = always power up in manual for
Loop 2; 1 = auto/manual selector unchanged at power up.

0

L146

5-9

CON1

Hard Manual Limit - 1 = apply output limits to the final output
of the Loop 2 Auto-Manual Generator. Affects both the
manual push buttons and the controller’s result. 0 = do not
apply limits.

1

C145

5-9

CON1

Output High Limit - Sets maximum Loop 2 Control Output
signal value in engineering units.

100

C146

5-9

CON1

Output Low Limit - Sets minimum Loop 2 Control Output
signal value in engineering units.

0

C154

5-9

CON1

Output Slew Rate - It is a rate limit applied to the output
value. When configured to a non-zero value, the output from
the Loop 2 Auto-Selector is only allowed to change by this
amount each scan time. A zero disables output slewing. It
does not affect manual operation.

0

6 of 13
