Table D-14. Database - L Type Datapoints
Data-
point
Name
Module
Atom
Default
Table
L074
User Log Enable
ULE
L075
Counter Mode
System
CMODE
0
5-14
L076
HiRes Disable
HD
0
L077
Display FTran Control
DFC
0
L078
SDT0 Process Alarm
SDT
SPA0
0
L079
SDT1 Process Alarm
SPA1
0
L080-
L103
FCS
0
L104
SP Track Status
Controller 0
SPTS0
0
5-9
L105
Output Track Status
OVTS0
0
L106
Reverse Switch
RSW0
1
L107
Auto Status
AUT0
0
L108
Remote Status
RMT0
0
L109
Reverse Valve
RSV0
0
L110
Alarm A Active
PA10
0
L111
Alarm B Active
PA20
0
L112
Auto Switch
SWA0
0
L113
Remote Switch
SWR0
0
L114
Auto Enable
AE0
1
L115
Remote Setpoint Enable
RE0
0
L116
Setpoint Track Switch
SWSPT0
0
L117
Output Track Switch
SWOVT0
0
L118
Setpoint Track Enable
STE0
0
L119
Output Track Enable
OTE0
0
L120
Manual Fallback Disable
MFD0
0
L121
Reserved
0
L122
Hard Manual Limit
Controller 0
HML0
1
5-9
L123
Control Track Command
CTC0
0
L124
Reserved
0
L125
Alarm Acknowledge
Controller 0
AK0
0
5-9
L126
Alarm AA Past State
LA0
0
L127
Alarm AB Past State
LB0
0
L128
SP Track Status
Controller 1
SPTS1
0
L129
Output Track Status
OVTS1
0
L130
Reverse Switch
RSW1
1
L131
Auto Status
AUT1
0
L132
Remote Status
RMT1
0
L133
Reverse Valve
RSV1
0
L134
Alarm A Active
PA11
0
L135
Alarm B Active
PA21
0
L136
Auto Switch
SWA1
0
L137
Remote Switch
SWR1
0
